2001 Fairchild Semiconductor Corporation
March 2001
Rev. A, March 2001
F
QF E T
TM
FQA13N80
800V N-Channel MOSFET
General Description
These N-Channel enhancement mode power field effect
transistors are produced using Fairchild’s proprietary,
planar stripe, DMOS technology.
This advanced technology has been especially tailored to
minimize on-state resistance, provide superior switching
performance, and withstand high energy pulse in the
avalanche and commutation mode. These devices are well
suited for high efficiency switch mode power supplies.
Features
12.6A, 800V, R
DS(on)
= 0.75
@V
GS
= 10 V
Low gate charge ( typical 68 nC)
Low Crss ( typical 30 pF)
Fast switching
100% avalanche tested
Improved dv/dt capability
Absolute Maximum Ratings
T
C
= 25°C unless otherwise noted
Thermal Characteristics
Symbol
V
DSS
I
D
Parameter
FQA13N80
800
12.6
8.0
50.4
±
30
1100
12.6
30
4.0
300
2.38
-55 to +150
Units
V
A
A
A
V
mJ
A
mJ
V/ns
W
W/°C
°C
Drain-Source Voltage
Drain Current
- Continuous (T
C
= 25°C)
- Continuous (T
C
= 100°C)
- Pulsed
I
DM
V
GSS
E
AS
I
AR
E
AR
dv/dt
P
D
Drain Current
Gate-Source Voltage
Single Pulsed Avalanche Energy
Avalanche Current
Repetitive Avalanche Energy
Peak Diode Recovery dv/dt
Power Dissipation (T
C
= 25°C)
(Note 1)
(Note 2)
(Note 1)
(Note 1)
(Note 3)
- Derate above 25°C
T
J
, T
STG
Operating and Storage Temperature Range
Maximum lead temperature for soldering purposes,
1/8
"
from case for 5 seconds
T
L
300
°C
Symbol
R
θ
JC
R
θ
CS
R
θ
JA
Parameter
Typ
--
0.24
--
Max
0.42
--
40
Units
°C
/
W
°C
/
W
°C
/
W
Thermal Resistance, Junction-to-Case
Thermal Resistance, Case-to-Sink
Thermal Resistance, Junction-to-Ambient
! "
!
!
S
!
"
"
D
G
TO-3P
FQA Series
G
S
D
