2006 Fairchild Semiconductor Corporation
F
April 3, 2006
Integrated Power Functions
600V-50A IGBT inverter for three-phase DC/AC power conversion (Please refer to Fig. 3)
Integrated Drive, Protection and System Control Functions
For inverter high-side IGBTs: Gate drive circuit, High voltage isolated high-speed level shifting
Control circuit under-voltage (UV) protection
Note) Available bootstrap circuit example is given in Figs. 13 and 14.
For inverter low-side IGBTs: Gate drive circuit, Short circuit protection (SC)
Control supply circuit under-voltage (UV) protection
Temperature Monitoring: System over-temperature monitoring using built-in thermistor
Note) Available temperature monitoring circuit is given in Fig. 14.
Fault signaling: Corresponding to a SC fault (Low-side IGBTs) or a UV fault (Low-side control supply circuit)
Input interface: 5V CMOS/LSTTL compatible, Schmitt trigger input
Pin Configuration
Fig. 2.
Top View
Detecting Point
(26)N
U
(23)V
S(W)
(7)V
FO
(8)C
FOD
(9)C
SC
(10)R
SC
(27)N
V
(28)N
W
(32)P
(21)V
CC(WH)
(29)U
(30)V
(31)W
(25)R
TH
(24)V
TH
(19)V
S(V)
(15)IN
V(H)
(17)V
CC(VH)
(16)COM
(H)
(14)V
S(U)
(11)IN
(UH)
(12)V
CC(UH)
DBC Substrate
Case Temperature(T
C
)
(22)V
B(W)
(1)V
CC(L)
(2)COM
(L)
(3)IN
(UL)
(4)IN
(VL)
(5)IN
(WL)
(6)COM
(L)
(20)IN
(WH)
(18)V
B(V)
(13)V
B(U)
