GTL2005_7
NXP B.V. 2009. All rights reserved.
Product data sheet
Rev. 07 — 3 February 2009
15 of 19
NXP Semiconductors
GTL2005
Quad GTL/GTL+ to LVTTL/TTL bidirectional non-latched translator
14.4 Reflow soldering
Key characteristics in reflow soldering are:
Lead-free versus SnPb soldering; note that a lead-free reflow process usually leads to
higher minimum peak temperatures (see
Figure 12
) than a SnPb process, thus
reducing the process window
Solder paste printing issues including smearing, release, and adjusting the process
window for a mix of large and small components on one board
Reflow temperature profile; this profile includes preheat, reflow (in which the board is
heated to the peak temperature) and cooling down. It is imperative that the peak
temperature is high enough for the solder to make reliable solder joints (a solder paste
characteristic). In addition, the peak temperature must be low enough that the
packages and/or boards are not damaged. The peak temperature of the package
depends on package thickness and volume and is classified in accordance with
Table 9
and
10
Moisture sensitivity precautions, as indicated on the packing, must be respected at all
times.
Studies have shown that small packages reach higher temperatures during reflow
soldering, see
Figure 12
.
Table 9.
Package thickness (mm)
SnPb eutectic process (from J-STD-020C)
Package reflow temperature (
°
C)
Volume (mm
3
)
< 350
235
220
≥
350
220
220
< 2.5
≥
2.5
Table 10.
Package thickness (mm)
Lead-free process (from J-STD-020C)
Package reflow temperature (
°
C)
Volume (mm
3
)
< 350
260
260
250
350 to 2000
260
250
245
> 2000
260
245
245
< 1.6
1.6 to 2.5
> 2.5
