CONFIDENT IAL & PROPRIET ARY
HM10S604 PRELIMINARY SPEC
I/O
DESCRIPTION
Sub-pixel output, provides 64 gray signals to the LCD panel.
O
Switched LCD drive capacity : BC = H : heavy load mode
BC = L : spec-load mode
I
Reduces charge and discharge current to a load
LP = H : normal mode
LP = L : low power mode
I
Detailed description
Image signal capture
DEIOn=H(n=1 or n=2) is captured internally at the leading edge of DCLK. After the decay of DEIOn, the image signal
data are captured in the internal latch with the rise of the next DCLK.
If DEIOn receives an input in the meantime, new image signal data is captured at the rise of the next DCLK after
DEIOn decays.
It is possible to reverse the input data for each port by means of the RVRS1 and RVRS2.
Output expansion
The number of image signal output terminals can be expanded by cascading these devices,thereby enabling
compatibility with large screens. Expansion is controlled by using the L/R terminal:
L/R=L : the previous stage DEIO1 terminals is connected to the next stage DEIO2, and input terminals other
than DEIO1 and DEIO2 are connected together on each device.
L/R=H : the previous stage DEIO2 terminals is connected to the next stage DEIO1, and input terminals other
than DEIO1 and DEIO2 are connected together on each device
Relationship between input data values and output voltage
The output voltage is determined by the input data value and the 10 gamma correction potentials, Also, since
the output voltage is compatible with dot reverse driving, it is possible to output gradation voltages for the
opposing electrode voltages with polarities that differ for even and odd numbered outputs.
Input potentials with the same polarities relative to the opposing electrode voltages should be applied for
GH63/GL63,GH47/GL47,GH31/GL31,GH15/GL15,GH0/GL0 of the gamma correction reference power
supply.
Reference potential input for correction ( i.e. GH63/GL63,GH47/GL47,GH31/GL31,GH15/GL15,GH0/GL0 )
should be applied externally as desired. Reference potential should be maintained during gradation voltage
output. Refer to the operating conditions for the relative magnitude of each potential.
NAME
TERMINAL
LP
Low power mode
selection terminal
BC
LCD drive capacity
switching terminal
OUT1 ~
OUT420
LCD control
output terminal
FUNCTION
