HSMB-C190, HSMB-C170, HSMB-C110,
HSMB-C150, HSMB-C191
Device Selection Guide
Footprint (mm)
2.00 x 1.25
1.60 x 0.80
3.20 x 1.00
[1]
3.20 x 1.60
Note:
1.
Right-anglepackage.
SiC Blue
HSMB-C170
HSMB-C190/C191
HSMB-C110
HSMB-C150
Parts Per Reel
4000
4000
3000
3000
CAUTION: HSMB-C1xx LEDs are Class 1A ESD sensitive per JESD22-A114C.01. Please observe appropriate precautions
during handling and processing. Refer to Avago Technologies Application Note AN-1142 for additional details.
HSMB-Cxxx
Surface Mount Chip LEDs
Data Sheet
Features
SmallSize
IndustryStandardFootprint
CompatiblewithIRSolder
DiffusedOptics
OperatingTemperatureRangeof–30°Cto+85°C
RightAnglePackageAvailable
SiCBlueColor
Availablein8mmTapeon7"(178mm)Diameter
Reels
Applications
KeypadBacklighting
Push-ButtonBacklighting
LCDBacklighting
SymbolBacklighting
FrontPanelIndicator
Description
TheseBluechipLEDsaredesignedinanindustrystandard
packageforeaseofhandlinganduse.Bluecolorchip
LEDisanewproductthatofferscolordifferentiationfor
backlightingapplications.
TheHSMB-C150hastheindustrystandard3.2x1.6mm
footprintthatisexcellentforallarounduse.TheHSMB-
C170hasthewidelyused2.0x1.25mmfootprint.The
HSMB-C190andHSMB-C191havetheindustrystandard
1.6x0.8mmfootprint,andtheirlowprofiles(0.8mmfor
HSMB-C190and0.6mmforHSMB-C191)andwideview-
inganglesmaketheseLEDsexceptionalforbacklighting
applications.
TheHSMB-C110isaright-anglepackagewiththeuniver-
sallyaccepteddimensionsof3.2x1.0x1.5mm.Thispartis
idealforLCDbacklightingandsidelightingapplications.
AllpackagesarecompatiblewithIRreflowsolderpro-
cesses.Thesmallsizeandwideviewinganglemakethese
LEDsprimechoicesforbacklightingapplicationsandfront
panelilluminationespeciallywherespaceisapremium.
