| 型號： | IRH8450 |
| 英文描述： | 500V 1000kRad Hi-Rel Single N-Channel TID Hardened MOSFET in a TO-204AA package |
| 中文描述： | 500V 1000kRad高可靠性單N溝道MOSFET的工貿硬化在TO - 204AA封裝 |
| 文件頁數： | 1/12頁 |
| 文件大小： | 350K |
| 代理商： | IRH8450 |
o
C
www.irf.com
1
A
Product Summary
Part Number
IRH7450
IRH8450
BV
DSS
500V
500V
R
DS(on)
0.45
0.45
I
D
11A
11A
Features:
n
Radiation Hardened up to 1 x 10
6
Rads (Si)
n
Single Event Burnout (SEB) Hardened
n
Single Event Gate Rupture (SEGR) Hardened
n
Gamma Dot (Flash X-Ray) Hardened
n
Neutron Tolerant
n
Identical Pre- and Post-Electrical Test Conditions
n
Repetitive Avalanche Rating
n
Dynamic dv/dt Rating
n
Simple Drive Requirements
n
Ease of Paralleling
n
Hermetically Sealed
Absolute Maximum Ratings
Parameter
Continuous Drain Current
Continuous Drain Current
Pulsed Drain Current
Max. Power Dissipation
Linear Derating Factor
Gate-to-Source Voltage
Single Pulse Avalanche Energy
Avalanche Current
Repetitive Avalanche Energy
Peak Diode Recovery dv/dt
Operating Junction
Storage Temperature Range
Lead Temperature
Weight
IRH7450, IRH8450
11
7.0
44
150
1.2
±20
500
11
15
3.5
-55 to 150
Units
ID @ VGS = 12V, TC = 25°C
ID @ VGS = 12V, TC = 100°C
IDM
PD @ TC = 25°C
W
W/°C
V
mJ
A
mJ
V/ns
VGS
EAS
IAR
EAR
dv/dt
TJ
TSTG
300 (0.063 in. (1.6mm) from case for 10s)
11.5 (typical)
g
PD - 91807A
Pre-Irradiation
500Volt, 0.45
, MEGA RAD HARD HEXFET
International Rectifier’s RAD HARD technology
HEXFETs demonstrate excellent threshold voltage
stability and breakdown voltage stability at total
radiaition doses as high as 1x10
6
Rads(Si). Under
identical
pre- and post-irradiation test conditions, In-
ternational Rectifier’s RAD HARD HEXFETs retain
identical
electrical specifications up to 1 x 10
5
Rads
(Si) total dose. No compensation in gate drive circuitry
is required. These devices are also capable of surviv-
ing transient ionization pulses as high as 1 x 10
12
Rads
(Si)/Sec, and return to normal operation within a few
microseconds. Since the RAD HARD process utilizes
International Rectifier’s patented HEXFET technology,
the user can expect the highest quality and reliability
in the industry.
RAD HARD HEXFET transistors also feature all of
the well-established advantages of MOSFETs, such
as voltage control, very fast switching, ease of paral-
leling and temperature stability of the electrical pa-
rameters. They are well-suited for applications such
as switching power supplies, motor controls, invert-
ers, choppers, audio amplifiers and high-energy
pulse circuits in space and weapons environments.
REPETITIVE AVALANCHE AND dv/dt RATED
HEXFET
TRANSISTOR
IRH7450
IRH8450
N CHANNEL
10/14/98
MEGA RAD HARD
