92706 / 41006 MS OT B8-5979, B8-5467 No.A0220-1/13
LA7138M
Overview
The LA7138M is a video output interface IC for DVD players. It is an ideal DVD player driver IC that generates analog
video signals such as composite/S and component/RGB signals. Incorporating Y/C-MIX, the LA7138M can dispense with
the composite output that would otherwise have to be provided by a DA converter.
Feature
Video S/N ratio: -80dB.
f characteristics: 10MHz flat.
Y/C time difference: 2ns maximum.
Signal dynamic range: 170 IRE.
Supports all types of video signals including the composite/S, component, and base-band (RGB) signals; the internal input
configuration is selected under microcontroller control (input capacitors to be used in common).
Provides two channels of 75 driver outputs each of which can be muted on and off independently under microcontroller
control.
Internally generates clamp pulses that are necessary when receiving the component input signals.
The amplifier gain is selectable from 8.5dB and 6dB.
The on-chip regulator circuit provides stable DC voltages that are immune to VCC fluctuations.
Function
Clamp.
Amplifier.
75 driver.
Y/C-MIX.
DC voltage output for S1 and S2.
Specifications
Maximum Ratings at Ta = 25
°C
Parameter
Symbol
Conditions
Ratings
Unit
Maximum supply voltage
VCC max
15.0
V
Allowable power dissipation
Pdmax
Ta
≤75°C, Mounted on a board*
525
mW
Operating temperature
Topr
-20 to +75
°C
Storage temperature
Tstg
-40 to +150
°C
*:
As mounted to the glass epoxy made board of a size 114.3
×76.1×1.6mm3
Ordering number : ENA0220
Monolithic Linear IC
For the DVD Player
Analog Video Signal I/F Driver
Any and all SANYO Semiconductor products described or contained herein do not have specifications
that can handle applications that require extremely high levels of reliability, such as life-support systems,
aircraft's control systems, or other applications whose failure can be reasonably expected to result in
serious physical and/or material damage. Consult with your SANYO Semiconductor representative
nearest you before using any SANYO Semiconductor products described or contained herein in such
applications.
SANYO Semiconductor assumes no responsibility for equipment failures that result from using products
at values that exceed, even momentarily, rated values (such as maximum ratings, operating condition
ranges, or other parameters) listed in products specifications of any and all SANYO Semiconductor
products described or contained herein.
