LC749402BG
No.A1618-8/11
Continued from preceding page.
In/output format
Pin No.
Pin symbol
I/O
Format
Connecting
destination
Remarks
J1
DCBIN0
I
C
CMOS
Digital
B/Cb/C video (LSB). Connect to GND when not to be used.
J2
DVSS
P
-
GND
Digital
J3
DCBIN3
I
C
CMOS
Digital
B/Cb/C video.
Connect this pin to GND when not to be used.
J4
DCBIN5
I
C
CMOS
Digital
B/Cb/C video.
Connect this pin to GND when not to be used.
J5
DDEI
I
C
CMOS
Digital
Data enable signal, Connect this pin to GND in the internal
generation mode
J6
DHSI
I
C
CMOS
Digital
Horizontal synchronizing signal
J7
GRST
O
F
CMOS
Digital
Reset signal for gate driver
J8
CPV
O
F
CMOS
Digital
Clock signal for gate driver
J9
DVDD_CORE
P
-
Core voltage
Digital
J10
SP
O
F
CMOS
Digital
Start pulse signal for source driver
K1
DVSS
P
-
GND
Analog
Connect this pin to J2 without fail
K2
DCBIN1
I
C
CMOS
Digital
B/Cb/C video.
Connect this pin to GND when not to be used.
K3
DCBIN2
I
C
CMOS
Digital
B/Cb/C video.
Connect this pin to GND when not to be used.
K4
DCBIN4
I
C
CMOS
Digital
B/Cb/C video.
Connect this pin to GND when not to be used.
K5
DCBIN7
I
C
CMOS
Digital
B/Cb/C video (MSB).
Connect this pin to GND when not to be used.
K6
DCKI
I
C
CMOS
Digital
Video clock
K7
XTAL1
I
C
CMOS
Digital
Panel protection, PWM generation clock.
Connect this pin to GND when not to be used.
K8
OE
O
F
CMOS
Digital
Output enable signal for gate driver
K9
STRB
O
F
CMOS
Digital
Data strobe signal for source driver
K10
DVDD_CORE
P
-
Core voltage
Digital
Connect this pin to J9 without fail
