SANYO Electric Co.,Ltd. Semiconductor Company
TOKYO OFFICE Tokyo Bldg., 1-10, 1 Chome, Ueno, Taito-ku, TOKYO, 110-8534 JAPAN
Ordering number : ENN8096A
70105HK OT B8-7981 No.8096-1/17
SANYO Semiconductors
DATA SHEET
LC749450NW
Silicon Gate CMOS IC
Digital RGB Image Processor IC
Any and all SANYO products described or contained herein do not have specifications that can handle
applications that require extremely high levels of reliability, such as life-support systems, aircraft's
control systems, or other applications whose failure can be reasonably expected to result in serious
physical and/or material damage. Consult with your SANYO representative nearest you before using
any SANYO products described or contained herein in such applications.
SANYO assumes no responsibility for equipment failures that result from using products at values that
exceed, even momentarily, rated values (such as maximum ratings, operating condition ranges, or other
parameters) listed in products specifications of any and all SANYO products described or contained
herein.
Overview
The LC749450NW RGB image processing IC converts interlaced video signals such as NTSC and PAL to progressive
scan and adjusts the image quality of that signal. Since the LC749450NW can operate at input clock frequencies up to
27 MHz, it is optimal as a pixel display device IC for high-quality high-resolution images. A high image quality
progressive scan signal playback system can be implemented easily by combining the LC749450NW with external
memory (two 16M SDRAMs).
Features
Accepts 30-bit (4:4:4) YCbCr signals, 20-bit (4:2:2) YCbCr signals, and 10-bit RT.656 signals as inputs.
Supports digital TV inputs (480i, 480p, 1080i, and 720p): 30-bit YCbCr digital signal input.
30-bit digital RGB signal inputs
Produces 30-bit and 24-bit digital RGB (or YCbCr) signal outputs
Provides both YCbCr/YPbPr
→ RGB conversion and RGB → YCbCr conversion
Motion adaptive jaggy-less interlaced to progressive conversion
3:2 pull down
Multiple noise reduction systems (1D, 2D, and 3D)
Cross color and cross luminance cancellers
Horizontal outline correction (LTI and CTI)
Sharpness (horizontal and vertical)
Sharpness adjuster (shading relief enhancement)
White and black level expansion, white text correction (blue stretch)
Flesh tone correction
Hue and color gain adjustments
Color exciter (6-phase RGBYMC independent saturation adjustment)
Brightness and contrast adjustment
White balance and black balance adjustment
Gamma correction (Independent RGB, programmable LUT system)
Dithering (10-bit and 8-bit)
Clamp control
Aspect ratio conversion (4:3
→ 16:9)
Clock generator (PLL) circuit
SDRAM interface
I2C bus and CPU interface circuits
SDPIC: SANYO Digital Picture Improvement Core
SDPIC is a registered trademark of SANYO Electric Co., Ltd.
