www.national.com
32
Revision 1.0
L
13.0 Usage Scenarios
(Continued)
13.0 Usage Scenarios
13.1 SCENARIO 1: POINT-TO-POINT
CONNECTION
LMX9820A acts only as slave, no further configuration is
required.
Example:
Sensor with LMX9820A; hand-held device with
standard Bluetooth option.
The SPP conformance of the LMX9820A allows any device
using the SPP to connect to the LMX9820A.
By switching to transparent mode automatically, the con-
troller has no need for an additional protocol layer; data is
sent raw to the other Bluetooth device.
On default, a PinCode is requested to block unallowed tar-
geting.
Figure 19. Point-to-Point Connection
Microcontroller
LMX9820A
Standard Device
with Bluetooth
Air Interface
UART
Search for Devices
Inquiry Request
Inquiry Response
Get Remote Services
Transparent Mode
No Bluetooth commands necessary,
only “connected” event indicated to controller.
Sensor Device
SDP Link Request
SDP Link Accept
Connected
on Port L
Service Browse
Service Response
Release SDP Link
Release Confirm
SPP Link Request
SPP Link Accept
Establish SPP Link
Link Established
The client software only
shows high level functions.
Raw Data
