參數資料
| 型號： | MAX9738EVKIT+ |
| 廠商： | Maxim Integrated Products |
| 文件頁數： | 9/14頁 |
| 文件大小： | 0K |
| 描述： | KIT EVALUATION FOR MAX9738 |
| 產品培訓模塊： | Lead (SnPb) Finish for COTS Obsolescence Mitigation Program |
| 標準包裝： | 1 |
| 放大器類型： | G 類 |
| 輸出類型： | 1-通道（單聲道） |
| 電源電壓： | 2.7 V ~ 5.5 V |
| 工作溫度： | -45°C ~ 85°C |
| 板類型： | 完全填充 |
| 已用 IC / 零件： | MAX9738 |
| 已供物品： | 板 |
| 相關產品： | MAX9738EWP+TG45-ND - IC AMP AUDIO PWR MONO G 20WLP |
MAX9738
16VP-P Class G Amplifier with
Inverting Boost Converter
4
_______________________________________________________________________________________
ELECTRICAL CHARACTERISTICS (continued)
(VDD = VBAT = SHDN = 3.6V, GND = 0V, VDD - VSS = 9V, RISET = 100kΩ, RIN+ = RIN- = 10kΩ, RFB+ = RFB- = 10kΩ, CL = open, RL = ∞,
C1 = 10μF, C2 = 10μF, C3 = 0.1μF, C4 = 0.1μF, TA = TMIN to TMAX, unless otherwise noted. Typical values are at TA = +25°C.) (Note 1)
PARAMETER
SYMBOL
CONDITIONS
MIN
TYP
MAX
UNITS
INVERTING BOOST CONVERTER (VDD - VSS = -8.75V)
Switching Frequency
1.5
MHz
FET On-Time
tFON
550
750
950
ns
Minimum FET Off-Time
100
220
350
ns
Peak Output Current
VDD > 3V, typical application circuit
(Note 9)
400
mA
FET Current Limit (DC)
TA = +25°C (Note 10)
0.77
1.1
1.35
A
FET Current Limit (Transient)
Typical application circuit, inductor ISAT
rating > 1.7A
1.6
A
FET On-Resistance
RDSON
ILX = 100mA, TA = +25°C
0.2
0.26
Ω
Regulated Output Voltage
VBAT - VSS
8.15
8.9
9.60
V
Transient Load Regulation
0 to 400mA load step, typical application
circuit
300
mV
Maximum Output Ripple
ILOAD = 20mA, typical application circuit
200
mVP-P
BST Shutdown Leakage
SHDN = 0V, LX = 0V, BST = 5V
0.01
1
μA
VBAT Shutdown Current
VBAT = VDD, SHDN = 0V, LX = 0V,
BST = 5V
0.01
3
μA
LX Shutdown Leakage
LX = 0V, SHDN = 0V, BST = 5V
0.01
3
μA
Note 1:
All devices are 100% production tested at TA = +25°C. Specifications over temperature limits are guaranteed by design.
Note 2:
Total quiescent current depends on overall efficiency and varies with the LX inductor value and ESR, diode turn-on volt-
age, and the parasitic losses in all external components.
Note 3:
Input DC bias voltage determines the maximum voltage swing of the input signal. An input signal with an amplitude
greater than the input DC bias voltage results in clipping.
Note 4:
Amplifier inputs AC-coupled to GND.
Note 5:
Voltage gain is defined as [VOUT+ - VOUT-]/[VIN+ - VIN-].
Note 6:
VOUT is defined as [VOUT+ - VOUT-].
Note 7:
Matching of external AC-coupling input capacitors and gain resistors is critical to achieving good CMRR.
Note 8:
Dynamic range calculated by measuring the RMS voltage difference between a -60dBFS output signal and the noise floor,
then adding 60dB. Full scale is defined as the output signal needed to achieve 1% THD+N.
Note 9:
Peak output current depends on external power-supply components and the signal frequency.
Note 10: Boost converter current limit is tested with a DC sweep. Actual current-limit values under transient conditions may be high-
er. At high input supply, VBAT, and low inductance, L, transient current limit might be higher than 1.7A.
