4 ______________________________________________________________________________________
MAX98500
Boosted 2.2W Class D Amplifier
with Automatic Level Control
ELECTRICAL CHARACTERISTICS (continued)
(VBAT = 3.6V, RL = J between SPKP and SPKN, AV = +6dB, CIN = 1FF, 20Hz to 22kHz AC measurement bandwidth, TA = TMIN to
TMAX, unless otherwise noted. Typical values are at TA = +25NC.) (Note 2)
Note 2: 100% production tested at TA = +25NC. Specifications over temperature limits are guaranteed by design.
Note 3: Amplifier inputs are AC-coupled to AGND.
Note 4: Mode transitions are controlled by SDSPK.
PARAMETER
SYMBOL
CONDITIONS
MIN
TYP
MAX
UNITS
Knee Resistor
RKNEE
TA = +25NC,
AV = 15.5dB
VKNEE = 3.25V
43.2
kI
VKNEE = 3.35V
37.4
VKNEE = 3.45V
32.4
VKNEE = 3.55V
27.4
VKNEE = 3.65V
23.2
VKNEE = 3.75V
18.7
VKNEE = 3.85V
15.0
DIGITAL INPUTS (SDBST, SDSPK)
Input Voltage High
ViH
1.4
V
Input Voltage Low
VIL
0.4
V
Input Capacitance
CIN
10
pF
Input Leakage Current
IIN
TA = +25NC
-1.0
+1.0
F
A
