10
MCF5407 Integrated ColdFire¨ Microprocessor
ColdFire Module Description
1.3.8 System Interface
The MCF5407 processor provides a direct interface to 8-, 16-, and 32-bit FLASH, SRAM, ROM, and
peripheral devices through the use of fully-programmable chip selects and write enables. Support for burst
ROMs is also included. Through the on-chip PLL, users can input a slower clock (25 to 54 MHz) that is
internally multiplied to create the faster processor clock (100 to 162 MHz).
1.3.8.1 External Bus Interface
The bus interface controller transfers information between the ColdFire core or DMA, and memory,
peripherals, or other devices on the external bus. The external bus interface provides up to 32 bits of address
bus space, a 32-bit data bus, and all associated control signals. This interface implements an extended
synchronous protocol that supports bursting operations.
Simple two-wire request/acknowledge bus arbitration between the MCF5407 processor and another bus
master, such as an external DMA device, is glueless with arbitration logic internal to the MCF5407
processor. Multiple-master arbitration is also available with some simple external arbitration logic.
1.3.8.2 Chip Selects
Eight fully-programmable chip select outputs support the use of external memory and peripheral circuits
with user-deTned wait-state insertion. These signals interface to 8-, 16-, or 32-bit ports. The base address,
access permissions, and internal bus transfer terminations are programmable with conTguration registers for
each chip select. CS0 also provides global chip select functionality of boot ROM upon reset for initializing
the MCF5407.
1.3.8.3 16-Bit Parallel Port Interface
A 16-bit general-purpose programmable parallel port serves as either an input or an output on a pin-by-pin
basis.
1.3.8.4 Interrupt Controller
The interrupt controller provides user-programmable control of ten internal peripheral interrupts and
implements four external Txed interrupt-request pins. Each internal interrupt can be programmed to any one
of seven interrupt levels and four priority levels within each of these levels. Additionally, the external
interrupt request pins can be mapped to levels 1, 3, 5, and 7 or levels 2, 4, 6, and 7. Autovector capability is
available for both internal and external interrupts.
1.3.8.5 JTAG
To help with system diagnostics and manufacturing testing, the MCF5407 processor includes dedicated
user-accessible test logic that complies with the IEEE 1149.1a standard for boundary-scan testability, often
referred to as the Joint Test Action Group, or JTAG. For more information, refer to the IEEE 1149.1a
standard.
1.3.9 System Debug Interface
The ColdFire processor core debug interface is provided to support system debugging in conjunction with
low-cost debug and emulator development tools. Through a standard debug interface, users can access real-
time trace and debug information. This allows the processor and system to be debugged at full speed without
the need for costly in-circuit emulators. The debug unit contained in the MCF5407 is a compatible upgrade
to the MCF52xx and MCF53xx debug modules with added breakpoint registers and support for I/O interrupt
request servicing while in emulator mode.
