MRF1057T1
2
MOTOROLA RF/IF DEVICE DATA
ELECTRICAL CHARACTERISTICS (TA = 25°C, unless otherwise noted.)
Characteristic
Symbol
Min
Typ
Max
Unit
OFF CHARACTERISTIC [Note 1]
Collector–Emitter Breakdown Voltage (IC = 0.1 mA, IB = 0)
V(BR)CEO
5.0
–
–
Vdc
Collector–Base Breakdown Voltage (IC = 0.1 mA, IE = 0)
V(BR)CBO
12
–
–
Vdc
Emitter–Base Breakdown Voltage (IE = 0.1 mA, IC = 0)
V(BR)CBO
2.5
–
–
Vdc
Emitter Cutoff Current (VEB = 1.0 V, IC = 0)
IEBO
–
–
0.1
A
Collector Cutoff Current (VCB = 1.0 V, IE = 0)
ICBO
–
0.2
A
ON CHARACTERISTIC [Note 1]
DC Current Gain (VCE = 3.0 V, IC = 3.0 mA)
hFE
100
–
200
–
DYNAMIC CHARACTERISTICS
Collector–Base Capacitance (VCB = 1.0 V, IE = 0, f = 1.0 MHz)
Ccb
–
0.52
–
pF
Current Gain Bandwidth Product (VCE = 3.0 V, IC = 20 mA,
f
τ
–
12
–
GHz
f = 1.0 GHz)
PERFORMANCE CHARACTERISTIC
Insertion Gain
|S21|2
dB
VCE = 1.0 V, IC = 1.0 mA, f = 1.0 GHz
–
7.0
–
VCE = 3.0 V, IC = 3.0 mA, f = 1.0 GHz
–
11
–
Maximum Stable Gain and/or Maximum Available Gain [Note 2]
MSG, MAG
dB
VCE = 1.0 V, IC = 1.0 mA, f = 1.0 GHz
–
10
–
VCE = 3.0 V, IC = 3.0 mA, f = 1.0 GHz
–
15
–
Minimum Noise Figure
NFmin
dB
VCE = 1.0 V, IC = 1.0 mA, f = 1.0 GHz
–
1.3
–
VCE = 3.0 V, IC = 3.0 mA, f = 1.0 GHz
–
1.1
–
Associated Gain at Minimum NF
GNF
dB
VCE = 1.0 V, IC = 1.0 mA, f = 1.0 GHz
–
9.0
–
VCE = 3.0 V, IC = 3.0 mA, f = 1.0 GHz
–
12
–
Output Power at 1.0 dB Gain Compression [Note 3] (VCE = 3.0 V,
P1dB
–
1.0
–
dBm
IC = 3.0 mA, f = 1.0 GHz)
–
–
Output Third Order Intercept [Note 3] (VCE = 3.0 V, IC = 3.0 mA,
OIP3
–
22
–
dBm
f = 1.0 GHz)
NOTES: 1. Pulse width
≤300 s, duty cycle ≤2% pulsed.
2. Maximum Available Gain and Maximum Stable Gain are defined by the K factor as follows:
MAG
+
|
S
21
S
12
K
" K2 * 1
|, if K u 1, MSG + |
S
21
S
12
|,if K t 1
3. Zin = 50 and Zout matched for optimum IP3.
