MRF1517NT1
3
RF Device Data
Freescale Semiconductor
Figure 1. 480 - 520 MHz Broadband Test Circuit
VDD
C7
R3
C8
C6
R2
RF
INPUT
RF
OUTPUT
Z2
Z3
Z6
C1
C3
C14
DUT
Z7
Z9
Z10
Z4
Z5
L1
Z8
N2
C18
B2
N1
+
C13
C4
C12
B1, B2
Short Ferrite Beads, Fair Rite Products
(2743021446)
C1
300 pF, 100 mil Chip Capacitor
C2, C3, C4, C10,
C12, C13
0 to 20 pF, Trimmer Capacitors
C5, C11
43 pF, 100 mil Chip Capacitors
C6, C18
120 pF, 100 mil Chip Capacitors
C7, C15
10 μF, 50 V Electrolytic Capacitors
C8, C16
0.1 μF, 100 mil Chip Capacitors
C9, C17
1,000 pF, 100 mil Chip Capacitors
C14
330 pF, 100 mil Chip Capacitor
L1
55.5 nH, 5 Turn, Coilcraft
N1, N2
Type N Flange Mounts
R1
15 Ω, 0805 Chip Resistor
R2
1.0 kΩ, 1/8 W Resistor
R3
33 kΩ, 1/2 W Resistor
Z1
0.315″ x 0.080″ Microstrip
Z2
1.415″ x 0.080″ Microstrip
Z3
0.322″ x 0.080″ Microstrip
Z4
0.022″ x 0.080″ Microstrip
Z5, Z6
0.260″ x 0.223″ Microstrip
Z7
0.050″ x 0.080″ Microstrip
Z8
0.625″ x 0.080″ Microstrip
Z9
0.800″ x 0.080″ Microstrip
Z10
0.589″ x 0.080″ Microstrip
Board
Glass Teflon, 31 mils, 2 oz. Copper
Z1
C2
VGG
C15
+
C9
B1
R1
C16
C17
C5
C11
C10
TYPICAL CHARACTERISTICS, 480 - 520 MHz
Pout, OUTPUT POWER (WATTS)
IRL,
INPUT
RETURN
LOSS
(dB)
5
15
25
10
2
0
10
1
Figure 2. Output Power versus Input Power
Pin, INPUT POWER (WATTS)
2
Figure 3. Input Return Loss versus
Output Power
P out
,
OUTPUT
POWER
(W
A
TTS)
0
6
0.8
0.2
4
0.6
1.0
0.4
0
3
10
8
520 MHz
500 MHz
480 MHz
5
46
8
79
20
520 MHz
500 MHz
480 MHz
VDD = 7.5 Vdc
