MRF1535T1 MRF1535FT1
15
RF Device Data
Freescale Semiconductor
CASE 1264A-02
ISSUE C
NOTES:
1. CONTROLLING DIMENSION: INCH.
2. INTERPRET DIMENSIONS AND TOLERANCES
PER ASME Y14.5M, 1994.
3. DIMENSIONS D AND E1 DO NOT INCLUDE MOLD
PROTRUSION. ALLOWABLE PROTRUSION IS
0.006 PER SIDE. DIMENSIONS D AND E1 DO
INCLUDE MOLD MISMATCH AND ARE
DETERMINED AT DATUM PLANE H.
4. DIMENSIONS b1 AND b3 DO NOT INCLUDE
DAMBAR PROTRUSION. ALLOWABLE DAMBAR
PROTRUSION SHALL BE 0.005 TOTAL IN EXCESS
OF THE b1 AND b2 DIMENSIONS AT MAXIMUM
MATERIAL CONDITION.
5. CROSSHATCHING REPRESENTS THE EXPOSED
AREA OF THE HEAT SLUG.
6. DIMENSION A2 APPLIES WITHIN ZONE J ONLY.
D
A
B
M
aaa
D
SEATING
PLANE
2X
b1
A
E1
DRAIN ID
e
4X
D
4X
b2
D1
A
M
aaa
DA
M
aaa
DA
E
DRAIN ID
Y
DIM
A
MIN
MAX
MIN
MAX
MILLIMETERS
0.098
0.106
2.49
2.69
INCHES
A1
0.038
0.044
0.96
1.12
D
0.926
0.934
23.52
23.72
D1
D2
E
0.492
0.500
12.50
12.70
E1
0.246
0.254
6.25
6.45
E2
P
0.126
0.134
3.20
3.40
b1
0.193
0.199
4.90
5.05
b3
0.088
0.094
2.24
2.39
e
c1
0.007
0.011
0.178
0.279
bbb
1
2
3
4
5
6
3
2
1
6
5
4
VIEW Y-Y
0.193 BSC
0.008
4.90 BSC
0.20
STYLE 1:
PIN 1. SOURCE (COMMON)
2. DRAIN
3. SOURCE (COMMON)
4. SOURCE (COMMON)
5. GATE
6. SOURCE (COMMON)
4X
b3
b2
0.078
0.084
1.98
2.13
NOTE 5
aaa
0.004
0.10
0.170 BSC
4.32 BSC
0.608 BSC
15.44 BSC
0.810 BSC
20.57 BSC
D2
E2
A
bbb
B
C
A1
c1
2X
P
M
aaa
DA B
ZONE "J"
F
F
0.025 BSC
0.64 BSC
A2
0.040
0.042
1.02
1.07
A2
6
TO-272-6
PLASTIC
MRF1535FT1
