參數資料
| 型號： | MRF18060BLR3 |
| 廠商： | FREESCALE SEMICONDUCTOR INC |
| 元件分類： | 功率晶體管 |
| 英文描述： | L BAND, Si, N-CHANNEL, RF POWER, MOSFET |
| 封裝： | ROHS COMPLIANT, NI-780, CASE 465-06, 2 PIN |
| 文件頁數： | 5/12頁 |
| 文件大小： | 337K |
| 代理商： | MRF18060BLR3 |
2
RF Device Data
Freescale Semiconductor
MRF18060BLR3 MRF18060BLSR3
Table 4. Electrical Characteristics (TC = 25°C unless otherwise noted)
Characteristic
Symbol
Min
Typ
Max
Unit
Off Characteristics
Drain-Source Breakdown Voltage
(VGS = 0 Vdc, ID = 10 μAdc)
V(BR)DSS
65
—
Vdc
Zero Gate Voltage Drain Current
(VDS = 26 Vdc, VGS = 0 Vdc)
IDSS
—
6
μAdc
Gate-Source Leakage Current
(VGS = 5 Vdc, VDS = 0 Vdc)
IGSS
—
1
μAdc
On Characteristics
Gate Threshold Voltage
(VDS = 10 Vdc, ID = 300 μAdc)
VGS(th)
2
—
4
Vdc
Gate Quiescent Voltage
(VDS = 26 Vdc, ID = 500 mAdc)
VGS(Q)
2.5
3.9
4.5
Vdc
Drain-Source On-Voltage
(VGS = 10 Vdc, ID = 2 Adc)
VDS(on)
—
0.27
—
Vdc
Dynamic Characteristics
Input Capacitance (Including Input Matching Capacitor in Package) (1)
(VDS = 26 Vdc ± 30 mV(rms)ac @ 1 MHz, VGS = 0 Vdc)
Ciss
—
160
—
pF
Output Capacitance (1)
(VDS = 26 Vdc ± 30 mV(rms)ac @ 1 MHz, VGS = 0 Vdc)
Coss
—
740
—
pF
Reverse Transfer Capacitance
(VDS = 26 Vdc ± 30 mV(rms)ac @ 1 MHz, VGS = 0 Vdc)
Crss
—
2.7
—
pF
Functional Tests (In Freescale Test Fixture, 50 ohm system)
Common-Source Amplifier Power Gain @ 60 W (2)
(VDD = 26 Vdc, IDQ = 500 mA, f = 1930 - 1990 MHz)
Gps
11.5
13
—
dB
Drain Efficiency @ 60 W(2)
(VDD = 26 Vdc, IDQ = 500 mA, f = 1930 - 1990 MHz)
η
40
45
—
%
Input Return Loss (2)
(VDD = 26 Vdc, Pout = 60 W CW, IDQ = 500 mA,
f = 1930 - 1990 MHz)
IRL
—
-10
dB
1. Part is internally matched both on input and output.
2. To meet application requirements, Freescale test fixtures have been designed to cover the full GSM1900 band, ensuring
batch-to-batch consistency.
