MRF5S21045NR1 MRF5S21045NBR1
1
RF Device Data
Freescale Semiconductor
RF Power Field Effect Transistors
N-Channel Enhancement-Mode Lateral MOSFETs
Designed for W- CDMA base station applications with frequencies from 2110
to 2170 MHz. Suitable for TDMA, CDMA and multicarrier amplifier applications.
To be used in Class AB for PCN- PCS/cellular radio and WLL applications.
Typical 2-Carrier W-CDMA Performance: VDD = 28 Volts, IDQ = 500 mA,
Pout = 10 Watts Avg., f = 2112.5 MHz, Channel Bandwidth = 3.84 MHz,
PAR = 8.5 dB @ 0.01% Probability on CCDF.
Power Gain — 14.5 dB
Drain Efficiency — 25.5%
IM3 @ 10 MHz Offset — -37 dBc in 3.84 MHz Channel Bandwidth
ACPR @ 5 MHz Offset — -39 dBc in 3.84 MHz Channel Bandwidth
Capable of Handling 5:1 VSWR, @ 28 Vdc, 2140 MHz, 45 Watts CW
Output Power
Features
Characterized with Series Equivalent Large-Signal Impedance Parameters
Internally Matched for Ease of Use
Qualified Up to a Maximum of 32 VDD Operation
Integrated ESD Protection
200°C Capable Plastic Package
N Suffix Indicates Lead-Free Terminations. RoHS Compliant.
In Tape and Reel. R1 Suffix = 500 Units per 44 mm, 13 inch Reel.
Table 1. Maximum Ratings
Rating
Symbol
Value
Unit
Drain-Source Voltage
VDSS
-0.5, +68
Vdc
Gate-Source Voltage
VGS
-0.5, +15
Vdc
Total Device Dissipation @ TC = 25°C
Derate above 25
°C
PD
130
0.74
W
W/
°C
Storage Temperature Range
Tstg
-65 to +150
°C
Operating Junction Temperature
TJ
200
°C
Table 2. Thermal Characteristics
Characteristic
Symbol
Value (1,2)
Unit
Thermal Resistance, Junction to Case
Case Temperature 80
°C, 45 W CW
Case Temperature 79
°C, 10 W CW
RθJC
1.35
1.48
°C/W
1. MTTF calculator available at http://www.freescale.com/rf. Select Software & Tools/Development Tools/Calculators to access MTTF
calculators by product.
2. Refer to AN1955, Thermal Measurement Methodology of RF Power Amplifiers. Go to http://www.freescale.com/rf.
Select Documentation/Application Notes - AN1955.
Document Number: MRF5S21045N
Rev. 4.1, 12/2009
Freescale Semiconductor
Technical Data
MRF5S21045NR1
MRF5S21045NBR1
2110-2170 MHz, 10 W AVG., 28 V
2 x W-CDMA
LATERAL N-CHANNEL
RF POWER MOSFETs
CASE 1484-04, STYLE 1
TO-272 WB-4
PLASTIC
MRF5S21045NBR1
CASE 1486-03, STYLE 1
TO-270 WB-4
PLASTIC
MRF5S21045NR1
Freescale Semiconductor, Inc., 2008-2009. All rights reserved.
