169
N
PBP
-SERIES
m
Features
(1)
For equipment designed to conform EMI
regulations such as VCCI, CISPR, FCC, VDE,
etc.
(2) Attenuates conductive emission from power
supply
(3) Leakage Current: 0.75mA max. (250V, 60Hz)
(4) Compact size
(5) Low price
m
Safety standard
UL1283,
CSA Std. C22. 2 No. 8
v
Request customer specification for further details of specifications, outline, characteristics, etc.
Read the instruction manual before usage.
v
Contact us about delivery before ordering.
m
Circuit
m
Outline drawing
m
Derating
m
Specifications
1
2
3
4
5
6
7
8
9
Rated voltage (AC, DC)
Rated current (AC, DC)
Test voltage (terminal to case, AC 1 minute)
Isolation resistance (terminal to case, 500VDC)
(Note)
Leakage current
DC
resistance
Temperature rise
Operating temperature range
Weight (typ)
250V
1500V
100M
min
0.35mA max.
0.75mA max.
30°C max.
–20 ~ +85°C
15g
0.5
max.
0.2
max.
0.1
max.
0.06
max.
Item
Model
PBP-3201-22
PBP-3202-22
PBP-3203-22
PBP-3204-22
1A
2A
3A
4A
125V, 60Hz
250V, 60Hz
(Note) : Value at Ta 55°C. Refer to the derating curve shown below at Ta > 55°C.
PBP-3203
PBP-3201
PBP-3202
PBP-3204
Case: Plastic(UL94V-0)
Unit: mm
