Small Plastic Package, Quad SPDT Analog Switch
PT0348 (09/09)
Ver: 1
1
Data Sheet
PI3A412
Features
CMOS Technology for Bus and Analog
Applications
Low On-Resistance: 0.5
Wide VDD Range: 1.8V to 4.2V
Rail-to-Rail Signal Range
High Off Isolation: -83dB @ 100kHz
Channel-to-Channel Crosstalk Rejection:
-97dB @ 100kHz
Break-Before-Make Switching
Extended Industrial Temperature Range:
-40°C to 85°C
ESD protection: 4kV(HBM)
Packaging (Pb-free & Green): 16-contact TQFN
(ZH16)
Ordering Information
Part Number
Package
PI3A412ZHE
Lead Free and Green TQFN-16
(ZH16)
Description
PI3A412 is a quad single-pole double throw (SPDT)
CMOS switch. It can be used as an analog switch or as a
low-delay bus switch. Specified over a wide operating
power supply voltage, 1.8V to 4.2V, the PI3A412 has an
On-Resistance of 0.5 at +4.2V.
Control inputs(Ax) are independent of supply voltage.
Application
Cell Phones
PDAs
MP3 Players
Portable Instrumentation
Computer Peripherals
Speaker Headset Switching
Power Routing
Relay Replacement
Audio and Video Signal Routing
PCMCIA Cards
Modems
