參數資料
型號： PKM4610PIPLA
廠商： ERICSSON POWER MODULES AB
元件分類： 電源模塊
英文描述： 1-OUTPUT 66 W DC-DC REG PWR SUPPLY MODULE
封裝： ROHS COMPLIANT, QUARTER BRICK, 8 PIN
文件頁數： 1/50頁
文件大?。?/td> 2484K
代理商： PKM4610PIPLA
Limited Internal
TABLE OF CONTENTS
1 (2)
Prepared (also subject responsible if other)
No.
HF/MPM/BP/Y Lars Rabenius
001 52-EN/LZT 146310
Approved
Checked
Date
Rev
Reference
(Lars Rabenius)
2006-02-22
A
Contents
General Information
.............................................................................. 2
Safety Specification
.............................................................................. 3
Absolute Maximum Ratings
.............................................................................. 4
Product Program
Ordering No.
1.5V/20A Electrical Specification
PKM 4318 PIOA .................................................... 5
1.5V/30A Electrical Specification
PKM 4418A PIOA .................................................. 8
1.8V/20A Electrical Specification
PKM 4318 PI ....................................................... 11
1.8V/30A Electrical Specification
PKM 4518A PI ..................................................... 14
1.8V/35A Electrical Specification
PKM 4618A PI ..................................................... 17
2.5V/20A Electrical Specification
PKM 4519 PI ....................................................... 20
2.5V/30A Electrical Specification
PKM 4719A PI ..................................................... 23
3.3V/15A Electrical Specification
PKM 4510 PI ....................................................... 26
3.3V/20A Electrical Specification
PKM 4610 PI ....................................................... 29
3.3V/25A Electrical Specification
PKM 4810A PI ..................................................... 32
5V/15A
Electrical Specification
PKM 4711 PI ....................................................... 35
5V/20A
Electrical Specification
PKM 4111 PI ....................................................... 38
12V/10.5A Electrical Specification PKM 4113 PI ....................................................... 41
EMC Specification
............................................................................ 44
Operating Information
............................................................................ 45
Thermal Consideration
............................................................................ 46
Connections
............................................................................ 47
Mechanical Information
............................................................................ 48
Soldering Information
............................................................................ 49
Delivery Information
............................................................................ 49
Product Qualification Specification ............................................................................ 50
Ericsson Internal
PRODUCT SPECIFICATION
1 (3)
Prepared (also subject responsible if other)
No.
MPM/BY/P Lars Rabenius
1/1301-BMR631 Uen
Approved
Checked
Date
Rev
Reference
Lars Rabenius
2006-01-31
B
Key Features
Industry standard Quarter-brick
57.9 x 36.8 x 12.7 mm (2.28 x 1.45 x 0.50 in.)
High efficiency, typ. 91 % at 2.5 V out full load
1500 Vdc input to output isolation
Meets isolation requirements equivalent to basic
insulation according to IEC/EN/UL 60950
Fast dynamic response, 100 ms ± 150 mV peak typ.
More than 1.55 million hours MTBF according to
Telcordia
General Characteristics
Output over voltage protection
Input under voltage protection
Over temperature protection
Soft start
Output short-circuit protection
Remote sense
Remote control
Output voltage adjust function
Highly automated manufacturing ensures quality
ISO 9001/14001 certified supplier
Safety Approvals
Design for Environment
Meets requirements in high-
temperature lead-free soldering
processes.
E
PKM4000 PI series
DC/DC converters, Input 36-75 V, Output 35A/126W
EN/LZT 146 310 R1A February 2006
Ericsson Power Modules AB
Technical Specication
