Electronic control gear
QUICKTRONIC for OSRAM DULUX L and OSRAM DULUX F, single-lamp version, long
QT 1x55,70/230-240
Page 1
l
b
a
h
b
h
Reference :
Mains voltage [V] :
QT 1x55,70/230-240
for lamp :
1 x DL55
230/240
Permissible voltage fluctuations
[V] :
198 - 254
Permissible battery voltage [V] :
Mains frequency [Hz] :
Mains current at 230 V/240 V/ A :
System wattage 230 V/240 V [W]
:
Temperature range [°C] :
176 - 254
Lamp start :
Warm start within 2 s
0/50 - 60
Operating frequency [kHz] :
approx.40
0,28
Power factor [c] :
0,97
61
Luminous flux [lm] :
4800
-25 - +50
Radio interference suppression :
to.DIN VDE 0875/CISPR 15/EN
55015
Harmonics :
to DIN VDE 0712 Part 23/EN
61000-3-2/EN 60929
Immunity :
to EN 61547
Length l [mm] :
Height h [mm] :
Standard pack [pcs] :
EAN 40 50300 :
359
Width b [mm] :
30
29
Distance between holes a [mm] :
350
20
Weight [g] :
340
479354
QUICKTRONIC and OSRAM DULUX L and OSRAM DULUX F lamps are the modern combination for excellent lighting comfort.
QUICKTRONIC, the fully electronic, high-frequency compact control gear offers greater comfort, greater economy and greater reliability than the
conventional choke/starter circuit.
QUICKTRONIC and OSRAM DULUX L make a significant contribution to modern lighting since they allow manufacturers to produce omnidirectional
compact ceiling luminaires with square louvres for an economical and pleasant light. The extra small dimensions of an OSRAM DULUX L 18W and
OSRAM DULUX F are of particular interest for high-power table and wall lights.
Comfort:
- Flicker-free lamp ignition with protective soft start
