參數資料
| 型號： | S201DH1 |
| 廠商： | SHARP ELECTRONICS CORP |
| 元件分類： | 繼電器，輸入/輸出模塊 |
| 英文描述： | TRIGGER OUTPUT SOLID STATE RELAY, 4000 V ISOLATION-MAX |
| 封裝： | PLASTIC, DIP-16 |
| 文件頁數： | 1/14頁 |
| 文件大小： | 261K |
| 代理商： | S201DH1 |
S101DH1 Series
S201DH1 Series
■ Features
IT(rms)≤1.5A, Non-Zero Cross type
DIP 16pin
Triac output SSR
1. Output current, IT(rms)≤1.5A
2. Non-zero crossing functionary
3. 16 pin DIP package
4. High repetitive peak off-state voltage
(VDRM : 600V, S201DH1 Series)
(VDRM : 400V, S101DH1 Series)
5. Superior noise immunity
(dV/dt : MIN. 200V/s, S101DH1)
(dV/dt : MIN. 100V/s, S201DH1)
6. Response time, ton : MAX. 100s
7. TV approval model is also available
8. Lead-free terminal components are also available
(see Model Line-up section in this datasheet)
9. High isolation voltage between input and output
(Viso(rms) : 4.0kV)
■ Description
S101DH1 Series and S201DH1 Series Solid State
Relays (SSR) are an integration of an infrared emitting
diode (IRED), a Phototriac Detector and a main output
Triac. These devices are ideally suited for controlling
high voltage AC loads with solid state reliability while
providing 4.0kV isolation (Viso(rms)) from input to
output.
1
Notice The content of data sheet is subject to change without prior notice.
In the absence of confirmation by device specification sheets, SHARP takes no responsibility for any defects that may occur in equipment using any SHARP
devices shown in catalogs, data books, etc. Contact SHARP in order to obtain the latest device specification sheets before using any SHARP device.
S101DH1 Series
S201DH1 Series
■ Agency approvals/Compliance
1. Isolated interface between high voltage AC devices
and lower voltage DC control circuitry.
2. Switching motors, fans, heaters, solenoids, and
valves.
3. Phase or power control in applications such as
lighting and temperature control equipment.
■ Applications
1. Recognized by UL508, file No. E94758 (as model No.
S101DH1/S201DH1)
2. Approved by CSA 22.2 No.14, file No. LR63705 (as
model No. S101DH1/S201DH1)
3. Approved by TV (only S201DH1Y series), DIN
EN60950 (Basic insulation class), file No. R9650377
(as model No. S201DH1Y)
4. Package resin : UL flammability grade (94V-0)
Sheet No.: D4-A01201EN
Date Mar. 31. 2004
SHARP Corporation
Zero cross type is also available.(S101DH2 Series/
S201DH2 Series)
