Features
l Small plastic package: 4.5 × 5.5 mm (S6174, S6874-10)
l Built-in signal processing circuit
l Photodiode length
S6174
: 1.65 mm
S6
874-10: 2.17 mm
S8041
: 3.0 mm
Applications
l Print start timing detection for laser printers, digital copiers, etc.
IC
Photo IC for laser beam synchronous detection
Photo IC for start timing detection for laser printers, etc.
S6174, S6874-10, S8041
S6174, S6874-10, S8041 are designed for laser beam synchronous detection in laser printers, etc. These photo ICs use a single-element
photodiode and a signal processing circuit integrated in a small package. For more precision printing, Hamamatsu also provides S5049 series
photo ICs using a dual-element photodiode.
s Absolute maximum ratings (Ta=25
°C)
Parameter
Symbol
S6174
S6874-10
S8041
Unit
Supply voltage
Vcc
-0.5 to +7
V
Power dissipation *
1
P
150
mW
Output voltage
Vo
-0.5 to Vcc
V
Output current
Io
20
mA
Ro terminal current
IRO
2mA
O p er atin g te m p er ature
Topr
-25 to +80
°C
Storage temperature
Tstg
-40 to +85
°C
Soldering
-
230
°C, 5 s
-
*1: Derate power dissipation at a rate of 2 mW/
°C above Ta=25 °C.
s Electrical and optical chara cteristics (Ta =25
°C, λ=780 n m, Vcc=V cc1=Vcc2=5 V, Ro=5.1 k, unless otherw ise noted)
S6174
S6874-10
S8041
Parameter
Symbol
Condition
Min.
Typ.
Max.
Min.
Typ.
Max.
Min.
Typ.
Max.
Unit
Supply voltage
Vcc
4.5
5.0
5.5
4.5
5.0
5.5
4.5
5.0
5.5
V
High level output voltage
VOH
Pin=0
4.9
-
4.9
-
4.9
-
V
Lo w level output voltage
VOL
Pin=200
W, IOL=10 mA
-0.4
0.6
-0.4
0.6
-0.4
0.6
V
Pin=0, at high level output
-
5
-
5
-
5
mA
Current consumption
ICC
Pin=200
W
-
6--
6
mA
T hreshold input po w er
PTH
55
70
85
55
70
85
60
75
90
W
H
→L propagation delay time
tPHL
--
400
--
400
--
400
L
→H propagation delay time
tPLH
-
600
-
600
-
600
Rise time
tr
--
200
--
200
--
200
Fall time
tf
Pin=200
W
Duty ratio 1: 1
RL=510
, CL=15 pF *2
-
100
-
100
-
100
ns
*2: Measured by pulse-driving a laser diode. Rise time (tr) and fall time (tf) of input light waveform are less than 1 ns.
