- 您現在的位置：買賣IC網 > PDF目錄85311 > SZB05A0A (SEOUL SEMICONDUCTOR CO LTD) T-1 SINGLE COLOR LED, BLUE, 2.9 mm PDF資料下載
參數資料
| 型號： | SZB05A0A |
| 廠商： | SEOUL SEMICONDUCTOR CO LTD |
| 元件分類： | LED |
| 英文描述： | T-1 SINGLE COLOR LED, BLUE, 2.9 mm |
| 封裝： | ROHS COMPLIANT, SMD, 2 PIN |
| 文件頁數： | 11/21頁 |
| 文件大小： | 616K |
| 代理商： | SZB05A0A |
Z-Power
LED
X10490
Z-Power
LED
X10490
Technical
Data
Sheet
Rev. 05
March 2011
www.seoulsemicon.com
: SSC-QP-7-07-12 (Rev.00)
19
Reflow Soldering Conditions / Profile
* Caution
1. Reflow soldering should not be done more than one time.
2. Repairs should not be done after the LEDs have been soldered. When
repair is unavoidable, suitable tools must be used.
3. Die slug is to be soldered.
4. When soldering, do not put stress on the LEDs during heating.
5. After soldering, do not warp the circuit board.
6. Recommend to use a convection type reflow machine with 7 ~ 8 zones.
Pre-heating
200
180
150
~
0
[]
220
240
260
Rising
5 °C/sec
Tm : Reflow machine setting temp (max 30 sec.)
Ts : Surface temp of PCB (min)
Ts : Surface temp of PCB (max)
Ts : Surface temp of PCB (recommend)
Cooling
-5 °C/sec
Time
[Hr]
