Characteristics of Z5 (Part no : SZB05A0A)
-Blue
1-1 Electro-Optical characteristics at 350mA
1-2 Absolute Maximum Ratings
Parameter
Symbol
Value
Unit
Min
Typ
Max
Luminous Flux [1]
ФV [2]
-
28
-
lm
Dominant Wavelength[3]
λ
D
-
465
-
nm
Forward Voltage [4]
VF
-
3.3
-
V
Thermal resistance (J to S)
RθJ-S
7.0
K /W
View Angle
2Θ
128
deg.
Parameter
Symbol
Value
Unit
Forward Current
IF
700
mA
Reverse Voltage
V
5
V
Power Dissipation
Pd
2.8
W
Junction Temperature
Tj
145(@ IF ≤ 700mA)
C
Operating Temperature
Topr
-40 ~ +100
C
Storage Temperature
Tstg
-40 ~ +100
C
ESD Sensitivity [5]
-
±
8,000V HBM
-
*Notes :
[1] SSC maintains a tolerance of ±10% on flux and power measurements.
[2] ФV is the total luminous flux output as measured with an integrating sphere.
[3] Dominant Wavelength is derived from the CIE 1931 Chromaticity diagram.
A tolerance of ±0.5nm for dominant wavelength.
[4] Tolerance is ±0.06V on forward voltage measurements
[5] A zener diode is included to protect the product from ESD.
