THMC45
SINGLE-PHASE 5VDC BRUSHLESS FAN DRIVER WITH SINGLE WIRE CONTROL INTERFACE
Product Preview
Supply Current DC Electrical Characteristics
(VPWR = 5V, Ta = -30 to +80°C Unless Otherwise Noted)
Symbol
Parameter
Conditions
Min
Typ
Max
Units
VPWR
Supply voltage
4.5
5
5.5
V
IVPWR
VPWR supply current
ILOAD = 200mA
5
mA
Idle condition,
In locked rotor detect
2mA
ISLEEP
Sleep-state current
PWM = 0V for >100s
10
A
Hall Sensor Signal Conditioning DC Characteristics
(VPWR = 5V, Ta = -30 to +80°C Unless Otherwise Noted)
Symbol
Parameter
Conditions
Min
Typ
Max
Units
IIB(HL)
Input bias current
(design target only)
1A
VICR(HL)
ICR(HL) common mode input
voltage range
1.0
3.5
V
VIO
Hall comparator input offset
voltage
-7
0
+7
mV
HBIAS Output DC Characteristics
(VPWR = 5V, Ta = -30 to +80°C Unless Otherwise Noted)
Symbol
Parameter
Conditions
Min
Typ
Max
Units
IIH
HBIAS Output High Leakage
VHBIAS = VPWR
-1
1
A
VOL
HBIAS Output Low Voltage
IHBIAS = TBDmA
1.0
3.5
V
PWM Input DC Characteristics
(VPWR = 5V, Ta = -30 to +80°C Unless Otherwise Noted)
Symbol
Parameter
Conditions
Min
Typ
Max
Units
VIH
PWM high level input voltage
2
V
VIL
PWM low level input voltage
0.8
V
IIH
PWM high level input current
PWM = 5V
-1
+1
A
IIL
PWM low-level input current
PWM = 0V
-1
+1
A
ITACH
Tachometer Pulse Sink
Current
1mA
OUTA, OUTB Phase Winding Driver Outputs DC Characteristics
(VPWR = 5V, TA = -30 to +80°C Unless Otherwise Noted)
Symbol
Parameter
Conditions
Min
Typ
Max
Units
ILEAK
OUTA,OUTB output leakage
current
VPWM = 0V for >100s,
VOUTx = 5V
-1
1
A
RDSON
OUTA, OUTB Low-Side
Output “ON” resistance
IOUTx = 200mA
VPWM = 2.5V
TA = 25°C
TBD
RDSON
OUTA, OUTB High-Side
Output “ON” resistance
IOUTx = -200mA
VPWM = 2.5V
TA = 25°C
TBD
