THS5651
10-BIT, 100 MSPS, CommsDAC
DIGITAL-TO-ANALOG CONVERTER
SLAS197A – JUNE 1999
25
POST OFFICE BOX 655303
DALLAS, TEXAS 75265
APPLICATION INFORMATION
Table 2. Bill of Materials (Continued)
QTY
REF. DES
PART NUMBER
DESCRIPTION
MFG.
4
R12, R19, R7, R9
1206
1206 Chip resistor, 33
, 1/4 W, 1%
5
R13, R17. R2, R21, R8
1206
1206 Chip resistor, 0
, 1/4 W, 1%
1
R14
3214W-1-502 E or equivalent
4 mm SM Pot, 5K
Bourns
1
R15
1206
1206 Chip resistor, 2.94K, 1/4 W, 1%
1
R16
1206
1206 Chip resistor, 3K, 1/4 W, 1%
3
R18, R24, R29
1206
1206 Chip resistor, 49.94K, 1/4 W, 1%
3
R20, R3, R6
1206
1206 Chip resistor, 10K, 1/4 W, 1%
1
R22
1206
1206 Chip resistor, 10K, 1/4 W, 1%
1
R23
1206
1206 Chip resistor, 100K, 1/4 W, 1%
1
R25
1206
1206 Chip resistor, TBD, 1/4 W, 1%
4
R26, R27, R28, R30
1206
1206 Chip resistor, 750K, 1/4 W, 1%
1
T1
T1-1T-KK81
RF Transformer, T1-1T-KK81
MiniCircuits
2
U1, U2
SN74LVT245BDW
Octal bus transceiver, 3-state,
SN74LVT245B
TI
1
U3
SN74AHCT1G00DBVR/
SN74AHC1G00DBVR
Single gate NAND, SN74AHC1G00
TI
1
U4
SN74AHCT1G32DBVR/
SN74AHCC1G32DBVR
Single 2 input positive or gate,
SN74AHC1G32
TI
THS5641
THS5641IDW
DAC, 2.7–5.5 V, 8 Bit, 125 MHz
TI
THS5651
THS5651IDW
DAC, 2.7–5.5 V, 10 Bit, 125 MHz
TI
THS5661
THS5661IDW
DAC, 2.7–5.5 V, 12 Bit, 125 MHz
TI
THS5671
THS5647IDW
DAC, 2.7–5.5 V, 14 Bit, 125 MHz
TI
1
SN74ALVC08
SN74ALVC08D
Quad AND gate
TI
1
LT1004D
LT1004CD-1-2/LT1004ID-1-2
Precision 1.2 V reference
TI
0
NOT INSTALLED
AD1580BRT
Precision voltage reference, not
installed
1
THS3001
THS3001CD/THS2001ID
THS3001 high-speed op amp
TI
4
W2
TSW-102-07-L-S or equivalent
2 position jumper_.1’’ spacing, W2
Samtec
3
W3
TSW-102-07-L-S or equivalent
3 position jumper_.1’’ spacing, W3
Samtec
2
2X3_JUMPER
TSW-102-07-L-S or equivalent
6-Pin header dual row, 0.025
×0.1,
2X3_JUMPER
Samtec
