SLOS660A
– JANUARY 2010 – REVISED MARCH 2011
IC FUNCTION CONTROL (Address: 1)
REGISTER
I2C BIT
LABEL
DEFAULT
DESCRIPTION
ADDRESS
01 (01H) – IC
7
Unused
1
Function Control
6
EN
1 (enabled)
Enables amplifier
5
SWS
0 (enabled)
Shutdown IC when bit = 1
4
Unused
0
3
FAULT
0
Changes to a 1 when there is a short at the output. Reset by writing a 0
2
Thermal
0
Changes to a 1 when die temperature is above 150
°C
1
Unused
1
0
NG_EN
1 (enabled)
Enables Noise Gate function
EN:
Enable bit for the audio amplifier channel. Amplifier is active when bit is high. This function is
gated by thermal and returns once the IC is below the threshold temperature
SWS:
Software shutdown control. The device is in software shutdown when the bit is '1' (control, bias
and oscillator are inactive). When the bit is '0' the control, bias and oscillator are enabled.
Fault:
This bit indicates that an over-current event has occurred on the channel with a '1'. This bit is
cleared by writing a '0' to it.
Thermal:
This bit indicates a thermal shutdown that was initiated by the hardware with a '1'. This bit is
deglitched and latched, and can be cleared by writing a '0' to it.
NG_EN:
Enable bit for the Noise Gate function. This function is enabled when this bit is high. This
function can only be enabled when the Compression ratio is not 1:1.
AGC ATTACK CONTROL (Address: 2)
REGISTER
I2C
LABEL
DEFAULT
DESCRIPTION
ADDRESS
BIT
02 (02H) –
7:6
Unused
00
AGC Attack
5:0
ATK_time
000101
AGC Attack time (gain ramp down)
Control
(6.4 ms/6 dB)
Per Step
Per 6 dB
90% Range
000001
0.1067 ms
1.28 ms
5.76 ms
000010
0.2134 ms
2.56 ms
11.52 ms
000011
0.3201 ms
3.84 ms
17.19 ms
000100
0.4268 ms
5.12 ms
23.04 ms
(time increases by 0.1067 ms with every step)
111111
6.722 ms
80.66 ms
362.99 ms
ATK_time
These bits set the attack time for the AGC function. The attack time is the minimum time
between gain decreases.
Copyright
2010–2011, Texas Instruments Incorporated
25
Product Folder Link(s): TPA2028D1
