| 型號： | TPS54225PWP |
| 廠商： | TEXAS INSTRUMENTS INC |
| 元件分類： | 穩壓器 |
| 英文描述： | 4.5 A SWITCHING REGULATOR, 700 kHz SWITCHING FREQ-MAX, PDSO14 |
| 封裝： | GREEN, PLASTIC, HTSSOP-14 |
| 文件頁數： | 1/23頁 |
| 文件大小： | 733K |
| 代理商： | TPS54225PWP |
V
(50mV/div)
OUT
I
(1 A/div)
OUT
100 s/div
m
SLVSA15C
– OCTOBER 2009 – REVISED FEBRUARY 2011
4.5V to 18V Input, 2-A Synchronous Step-Down SWIFTTM Converter
Check for Samples: TPS54225
1
FEATURES
DESCRIPTION
23
D-CAP2
Mode Enables Fast Transient
Response
The TPS54225 is an adaptive on-time D-CAP2
mode synchronous buck converter. The TPS54225
Low Output Ripple and Allows Ceramic Output
enables system designers to complete the suite of
Capacitor
various end equipment
’s power bus regulators with a
Wide VCC Input Voltage Range: 4.5 V to 18 V
cost effective, low component count, low standby
Wide VIN Input Voltage Range: 2 V to 18 V
current solution. The main control loop for the
TPS54225 uses the D-CAP2
mode control which
Output Voltage Range: 0.76 V to 5.5 V
provides a fast transient response with no external
Highly Efficient Integrated FET
’s Optimized
compensation components.
for Lower Duty Cycle Applications
The TPS54225 also has a proprietary circuit that
- 160 m
(High Side) and 110 m (Low Side)
enables the device to adapt to both low equivalent
High Efficiency, less than 10
μA at shutdown
series resistance (ESR) output capacitors, such as
High Initial Bandgap Reference Accuracy
POSCAP or SP-CAP, and ultra-low ESR ceramic
Adjustable Soft Start
capacitors. The device operates from 4.5-V to 18-V
VCC input , and from 2-V to 18-V VIN input power
Pre-Biased Soft Start
supply
voltage.
The
output
voltage
can
be
700-kHz Switching Frequency (fSW)
programmed between 0.76 V and 5.5 V. The device
Cycle-By-Cycle Overcurrent Limit
also features an adjustable slow start time and a
power good function. The TPS54225 is available in
Power Good Output
the 14 pin HTSSOP package, and designed to
operate from
–40°C to 85°C.
APPLICATIONS
Wide Range of Applications for Low Voltage
System
– Digital TV Power Supply
– High Definition Blu-ray Disc Players
– Networking Home Terminal
– Digital Set Top Box (STB)
space
1
Please be aware that an important notice concerning availability, standard warranty, and use in critical applications of Texas
Instruments semiconductor products and disclaimers thereto appears at the end of this data sheet.
2
D-CAP2, PowerPAD are trademarks of Texas Instruments.
3
Blu-ray Disc is a trademark of Blu-ray Disc Association.
PRODUCTION DATA information is current as of publication date.
2009–2011, Texas Instruments Incorporated
Products conform to specifications per the terms of the Texas
Instruments standard warranty. Production processing does not
necessarily include testing of all parameters.
