| 型號： | TS12A4516P |
| 廠商： | TEXAS INSTRUMENTS INC |
| 元件分類： | 多路復用及模擬開關 |
| 英文描述： | 1-CHANNEL, SGL POLE SGL THROW SWITCH, PDIP8 |
| 封裝： | PLASTIC, DIP-8 |
| 文件頁數： | 1/13頁 |
| 文件大小： | 404K |
| 代理商： | TS12A4516P |
www.ti.com
FEATURES
DESCRIPTION/ORDERING INFORMATION
DUAL SUPPLY, LOW ON-STATE RESISTANCE
SPST CMOS ANALOG SWITCHES
SCDS236A – DECEMBER 2006 – REVISED MARCH 2007
±1-V to ±6-V Dual-Supply Operation
Specified Low ON-Leakage Currents:
Specified ON-State Resistance:
–
5 nA at 25
°C
–
25
Max With ±5-V Supply
–
10 nA at 85
°C
–
35
Max With ±3.3-V Supply
Low Charge Injection: 13 pC (±5-V Supply)
–
47
Max With ±1.8-V Supply
Fast Switching Speed:
t
ON = 85 ns, tOFF = 50 ns (±5-V Supply)
Specified Low OFF-Leakage Currents:
Break-Before-Make Operation (t
ON > tOFF)
–
5 nA at 25
°C
–
10 nA at 85
°C
The TS12A4516/TS12A4517 are single pole/single throw (SPST), low-voltage, dual-supply CMOS analog
switches, with very low switch ON-state resistance. The TS12A4516 is normally open (NO). The TS12A4517 is
normally closed (NC).
These CMOS switches can operate continuously with a dual supplies between
±1 V and ±6 V [(2 V < (V
+ – V–) <
12 V]. Each switch can handle rail-to-rail analog signals. The OFF-leakage current maximum is only 5 nA at
25
°C or 10 nA at 85°C.
For pin-compatible parts for use with single supply, see the TS12A4514/TS12A4515.
ORDERING INFORMATION
TA
PACKAGE(1)
ORDERABLE PART NUMBER
TOP-SIDE MARKING
PDIP – P
Reel of 2000
TS12A4516P
PREVIEW
Reel of 1500
TS12A4516D
SOIC – D
YD516
Reel of 2500
TS12A4516DR
SOP (SOT-23) – DBV
Reel of 3000
TS12A4516DBVR
PREVIEW
–40
°C to 85°C
PDIP – P
Reel of 2000
TS12A4517P
PREVIEW
Reel of 1500
TS12A4517D
SOIC – D
YD517
Reel of 2500
TS12A4517DR
SOP (SOT-23) – DBV
Reel of 3000
TS12A4517DBVR
PREVIEW
(1)
For the most current package and ordering information, see the Package Option Addendum at the end of this document, or see the TI
website at www.ti.com.
Please be aware that an important notice concerning availability, standard warranty, and use in critical applications of Texas
Instruments semiconductor products and disclaimers thereto appears at the end of this data sheet.
UNLESS
OTHERWISE
NOTED
this
document
contains
Copyright 2006–2007, Texas Instruments Incorporated
PRODUCTION DATA information current as of publication date.
Products conform to specifications per the terms of Texas
Instruments standard warranty. Production processing does not
necessarily include testing of all parameters.
