SLES243E
– JULY 2009 – REVISED MARCH 2011
5
Electrical Specifications
5.1
Absolute Maximum Ratings
(1)
over operating free-air temperature range (unless otherwise noted)
VDD_3_3 to VSS_3_3
0.5 V to 4.0 V
VDD_1_1 to VSS_1_1
-0.2 V to 1.2 V
VDD
Supply voltage range
VDDA_3_3 to VSSA_3_3
-0.3 V to 3.6 V
VDDA_1_8 to VSSA_1_8
-0.2 V to 2.0 V
VDDA_1_1 to VSSA_1_1
-0.2 V to 1.2 V
VI
Digital input voltage range
VI to DGND
-0.5 V to 4.5 V
VO
Digital output voltage range
VO to DGND
-0.5 V to 4.5 V
Analog video input voltage range
AIN to AGND
-0.2 V to 2.5 V
Analog audio input voltage range
AIN to AGND
-0.2 V to 2.0 V
Commercial range
0
°C to 70°C
TA
Operating free-air temperature range
Industrial range
-40
°C to 85°C
Tstg
Storage temperature range
-65
°C to 150°C
All pins
>500 V
JEDEC(3)
Excluding VSSA, VDD1_1,
>1000 V
XTAL_REF pins
Human-body model
(HBM)
All pins
>500 V
AEC-Q100(4)
Excluding VSSA, VDD1_1,
VESD
ESD stress voltage(2)
>1000 V
XTAL_REF pins
All pins
>250 V
JEDEC(5)
Charged-device
Excluding VSSA, VDD1_1,
>500 V
model (CDM)
XTAL_REF pins
AEC-Q100(6)
All pins
>400 V
(1)
Stresses beyond those listed under absolute maximum ratings may cause permanent damage to the device. These are stress ratings
only, and functional operation of the device at these or any other conditions beyond those indicated under recommended operating
conditions is not implied. Exposure to absolute-maximum-rated conditions for extended periods may affect device reliability.
(2)
Electrostatic discharge (ESD) to measure device sensitivity/immunity to damage caused by electrostatic discharges into the device.
(3)
Level listed is the passing level per ANSI/ESDA/JEDEC JS-001-2010. JEDEC document JEP155 states that 500V HBM allows safe
manufacturing with a standard ESD control process, and manufacturing with less than 500V HBM is possible if necessary precautions
are taken. Pins listed as 1000V may actually have higher performance.
(4)
Tested per AEC Q100-002 rev D
(5)
Level listed is the passing level per EIA-JEDEC JESD22-C101E. JEDEC document JEP157 states that 250V CDM allows safe
manufacturing with a standard ESD control process. Pins listed s 250V may actually have higher performance.
(6)
Tested per AEC Q100-011 rev B
Copyright
2009–2011, Texas Instruments Incorporated
Electrical Specifications
89
