參數資料
型號: UDA1335H
廠商: NXP SEMICONDUCTORS
元件分類: 消費家電
英文描述: Universal Serial Bus USB Audio Playback Recording Peripheral APRP
中文描述: SPECIALTY CONSUMER CIRCUIT, PQFP64
封裝: 14 X 20 MM, 2.80 MM HEIGHT, PLASTIC, SOT-319-2, QFP-64
文件頁數: 9/44頁
文件大小: 254K
代理商: UDA1335H
1998 Aug 28
9
Philips Semiconductors
Preliminary specification
Universal Serial Bus (USB) Audio
Playback Recording Peripheral (APRP)
UDA1335H
FUNCTIONAL DESCRIPTION
The Universal Serial Bus (USB)
Data and power is transferred via the USB over a 4-wire
cable. The signalling occurs over two wires and
point-to-point segments. The signals on each segment are
differentially driven into a cable of 90
intrinsic
impedance. The differential receiver features input
sensitivity of at least 200 mV and sufficient common mode
rejection.
The analog front-end
The analog front-end is an on-chip generic USB
transceiver. It is designed to allow voltage levels up to V
DD
from standard or programmable logic to interface with the
physical layer of the USB. It is capable of receiving and
transmitting serial data at full speed (12 Mbits/s).
The USB processor
The USB processor forms the interface between the
analog front-end, the ADIF, the ADAC and the
microcontroller. The USB processor consists of:
The Philips Serial Interface Engine (PSIE)
The Memory Management Unit (MMU)
The Audio Sample Redistribution (ASR) module.
The Philips Serial Interface Engine and Memory
Management Unit (PSIE/MMU)
The PSIE/MMU translates the electrical USB signals into
bytes and signals. Depending upon the USB device
address and the USB endpoint address, the USB data is
directed to the correct endpoint buffer on the PSIE/MMU
interface. The data transfer could be of bulk, isochronous,
control or interrupt type. The USB device address is
configured during the enumeration process.
The UDA1335H has four endpoints. These are:
Control endpoint 0
Status interrupt endpoint
Isochronous data sink endpoint
Isochronous data source endpoint.
The amount of bytes/packet on the control endpoint is
limited by the PSIE/MMU hardware to 8 bytes/packet.
The PSIE is the digital front-end of the USB processor.
This module recovers the 12 MHz USB clock, detects the
USB sync word and handles all low-level USB protocols
and error checking.
The MMU is the digital back-end of the USB processor.
It handles the temporary data storage of all USB packets
that are received or sent over the bus. Three types of
packets are defined on the USB. These are:
Token packets
Data packets
Handshake packets.
The token packet contains information about the
destination of the data packet. The audio data is
transferred via an isochronous data sink endpoint or
source endpoint and, consequently, no handshaking
mechanism is used. The MMU also generates a 1 kHz
clock that is locked to the USB Start Of Frame (SOF)
token.
The Audio Sample Redistribution (ASR)
The ASR reads the audio samples from the MMU and
distributes these samples equidistant over a 1 ms frame
period. The distributed audio samples are translated by
the digital I/O module to standard I
2
S-bus format or
Japanese digital I/O format. The ASR generates the bit
clock and the word select signal of the digital I/O.
The digital I/O formats the received audio samples to one
of the four specified serial digital audio formats
(I
2
S-bus, 16, 18 or 20 bits LSB-justified).
The microcontroller
The microcontroller receives the control information
selected from the USB by the USB processor. It handles
the high-level USB protocols and the user interfaces.
The major task of the software process, that is mapped
upon the microcontroller, is to control the different modules
of the UDA1335H in such a way that it behaves as a USB
device.
Therefore the microcontroller:
Interprets the USB requests and maps them upon the
UDA1335H application
Controls the internal operation of the UDA1335H, the
digital I/O pins and the GP I/O pins
Communicates with the external world (external
controller, EEPROM) using the I
2
C-bus facility and the
GP I/O pins.
The microcontroller does not handle the audio stream.
The UDA1335H will be delivered with USB compliant
firmware. The firmware must be located in an external
(E)PROM.
