W83194R-630
166MHZ CLOCK FOR SIS CHIPSET
Publication Release Date: Nov. 1999
- 1 - Revision 0.65
1. GENERAL DESCRIPTION
The W83194R-630 is a Clock Synthesizer for SiS 540/630 chipset. W83194R-630 provides all clocks
required for high-speed RISC or CISC microprocessor such as AMD,Cyrix,Intel Pentium, Pentium II
and also provides 16 different frequencies of CPU clocks frequency setting. All clocks are externally
selectable with smooth transitions. The W83194R-630 makes SDRAM in synchronous or
asynchronous frequency with CPU clocks.
The W83194R-630 provides I
2
C serial bus interface to program the registers to enable or disable
each clock outputs and W83194R-630 provides the 0.5%, 0.75% center type and 0~0.5% down type
spread spectrum to reduce EMI.
The W83194R-630 accepts a 14.318 MHz reference crystal as its input and runs on a 3.3V supply.
High drive PCI and SDRAM CLOCK outputs typically provide greater than 1 V /ns slew rate into 30
pF loads. CPU CLOCK outputs typically provide better than 1 V /ns slew rate into 20 pF loads as
maintaining 50
±
5% duty cycle. The fixed frequency outputs as REF, 24MHz, and 48 MHz provide
better than 0.5V /ns slew rate.
2. PRODUCT FEATURES
Supports Pentium
, Pentium
II, AMD and Cyrix CPUs with I
2
C.
3 CPU clocks
14 SDRAM clocks for 3 DIMMs
7 PCI synchronous clocks.
Optional single or mixed supply:
(All Vdd = 3.3V) or (Other s Vdd = 3.3V, VddLCPU=2.5V)
Skew form CPU to PCI clock 1 to 4 ns, center 2.6 ns
SDRAM frequency synchronous or asynchronous to CPU clocks
Smooth frequency switch with selections from 66 to 166mhz
I
2
C 2-Wire serial interface and I
2
C read back
0.5%, 0.75%center type, 0~0.5% down type spread spectrum to reduce EMI
Programmable registers to enable/stop each output and select modes
(mode as Tri-state or Normal )
48 MHz for USB
24 MHz for super I/O
Packaged in 48-pin SSOP
