REV. A
AD8306
–4–
ENABLE VOLTAGE – V
100
0.5
SUPPLY
CURRENT
–
mA
10
1
0.1
0.01
0.001
0.0001
0.00001
0.7
0.9
1.1
1.3
1.5
1.7
1.9
2.1
2.3
2.5
TA = +25 C
TA = +85 C
TA = –40 C
Figure 1. Supply Current vs. Enable Voltage @
TA = –40°C, +25°C and +85°C
RLIM –
14
0
SUPPLY
CURRENT
–
mA
12
10
8
6
4
2
0
50
100
150
200
250
300
350
400
450
ADDITIONAL SUPPLY CURRENT
LIMITER OUTPUT
CURRENT
Figure 2. Additional Supply Current and Limiter Output
Current vs. RLIM
500mV PER
VERTICAL
DIVISION
2V PER
VERTICAL
DIVISION
VLOG
GROUND REFERENCE
INPUT
100ns PER HORIZONTAL DIVISION
Figure 3. Large Signal RSSI Pulse Response with
CL = 100 pF and RL = 50 and 75 (Curves Overlap)
–Typical Performance Characteristics
500mV PER
VERTICAL
DIVISION
GROUND REFERENCE
INPUT
1V PER
VERTICAL
DIVISION
100ns PER HORIZONTAL DIVISION
INPUT LEVEL
SHOWN IS –3dBV
VLOG
Figure 4. RSSI Pulse Response for Inputs Stepped from
Zero to –83 dBV, –63 dBV, –43 dBV, –23 dBV, –3 dBV
500mV PER
VERTICAL
DIVISION
100ns PER HORIZONTAL DIVISION
INPUT
2V PER
VERTICAL
DIVISION
GROUND REFERENCE
VLOG
Figure 5. Large Signal RSSI Pulse Response with RL = 100
and CL = 33 pF, 100 pF and 330 pF (Overlapping Curves)
200mV PER
VERTICAL
DIVISION
GROUND REFERENCE
100 s PER HORIZONTAL DIVISION
270pF
27pF
3300pF
VLOG
Figure 6. Small Signal AC Response of RSSI Output with
External Filter Capacitance of 27 pF, 270 pF and 3300 pF
