2002 Mar 27
3
Philips Semiconductors
Product specication
Schottky barrier double diode
BAS40-07V
ELECTRICAL CHARACTERISTICS
Tamb =25 °C unless otherwise specied.
Note
1. Pulsed test: tp = 300 s; δ = 0.02.
THERMAL CHARACTERISTICS
Notes
1. Refer to SOT666 standard mounting conditions.
Soldering
The only recommended soldering is reflow soldering.
SYMBOL
PARAMETER
CONDITIONS
MAX.
UNIT
Per diode
VF
continuous forward voltage
see Fig.2
IF = 1 mA
380
mV
IF = 10 mA
500
mV
IF =40mA
1
V
IR
continuous reverse current
VR = 30 V; see Fig.3; note 1
1
A
VR = 40 V; see Fig.3; note 1
10
A
Cd
diode capacitance
VR = 0 V; f = 1 MHz; see Fig.5
5
pF
SYMBOL
PARAMETER
CONDITIONS
VALUE
UNIT
Rth j-a
thermal resistance from junction to ambient
note 1
416
K/W
