2000 Feb 04
2
Philips Semiconductors
Preliminary specication
Low-voltage low-power stereo audio
CODEC with DSP features
UDA1344TS
FEATURES
General
Low power consumption
3.0 V power supply
System clock of 256fs, 384fs and 512fs
Supports sampling frequencies from 8 to 55 kHz
Non-inverting ADC plus integrated high-pass filter to
cancel DC offset
ADC supports 2 V (RMS) input signals
Overload detector for easy record level control
Separate power control for ADC and DAC
Integrated digital interpolation filter plus non-inverting
DAC
Functions controllable either via L3 microcontroller
interface or via static pins
UDA1344TS is pin and function compatible with
UDA1340M
Small package size (SSOP28)
Easy application.
Multiple format input interface
I2S-bus, MSB-justified or LSB-justified
16, 18 and 20 bits format compatible
Three combined data formats with MSB-justified output
and LSB-justified 16, 18 and 20 bits input
1fs input and output format data rate.
DAC digital sound processing
The sound processing features of the UDA1344TS can be
used in the L3 mode only:
Digital tone control, bass boost and treble
Digital dB-linear volume control (low microcontroller
load) via L3 microcontroller
Digital de-emphasis for 32, 44.1 and 48 kHz
Soft mute.
Advanced audio conguration
Stereo single-ended input configuration
Stereo line output (under microcontroller volume
control), no post filter required
High linearity, dynamic range and low distortion.
GENERAL DESCRIPTION
The UDA1344TS is a single-chip stereo Analog-to-Digital
Converter (ADC) and Digital-to-Analog Converter (DAC)
with signal processing features employing bitstream
conversion techniques. The low power consumption and
low voltage requirements make the device eminently
suitable for use in low-voltage low-power portable digital
audio equipment which incorporates recording and
playback functions.
The UDA1344TS supports the I2S-bus data format with
word lengths of up to 20 bits, the MSB-justified data format
with word lengths of up to 20 bits and the LSB-justified
data format with word lengths of 16, 18 and 20 bits. The
UDA1344TS also supports three combined data formats
with MSB-justified data output and LSB-justified
16, 18 and 20 bits data input.
The UDA1344TS can be controlled either via static pins or
via the L3 interface. In the L3 mode the UDA1344TS has
special Digital Sound Processing (DSP) features in
playback mode such as de-emphasis, volume control,
bass boost, treble and soft mute.
ORDERING INFORMATION
TYPE
NUMBER
PACKAGE
NAME
DESCRIPTION
VERSION
UDA1344TS
SSOP28
plastic shrink small outline package; 28 leads; body width 5.3 mm
SOT341-1
