REV. C
–10–
AD7713
PGA Gain
G2
0
0
0
0
1
1
1
1
Gl
0
0
1
1
0
0
1
1
G0
0
1
0
1
0
1
0
1
Gain
1
2
4
8
16
32
64
128
(Default Condition After the Internal Power-On Reset)
Channel Selection
CH1 CH0 Channel
0
0
0
1
1
0
AIN1
AIN2
AIN3
(Default Condition After the Internal Power-On Reset)
Word Length
WL
Output Word Length
0
16-Bit
1
24-Bit
(Default Condition After Internal Power-On Reset)
RTD Excitation Currents
RO
0
Off
1
On
(Default Condition After Internal Power-On Reset)
Burn-Out Current
BO
0
Off
1
On
(Default Condition After Internal Power-On Reset)
Bipolar/Unipolar Selection (Both Inputs)
B/U
0 Bipolar
(Default Condition After Internal Power-On Reset)
1 Unipolar
Filter Selection (FS11–FS0)
The on-chip digital filter provides a Sinc
3
(or (Sinx/x)
3
) filter response. The 12 bits of data programmed into these bits determine
the filter cutoff frequency, the position of the first notch of the filter and the data rate for the part. In association with the gain selec-
tion, it also determines the output noise (and hence the effective resolution) of the device.
The first notch of the filter occurs at a frequency determined by the relationship: filter first notch frequency = (f
CLK IN
/512)/
code
where
code
is the decimal equivalent of the code in bits FS0 to FS11 and is in the range 19 to 2,000. With the nominal f
CLK IN
of
2 MHz, this results in a first notch frequency range from 1.952 Hz to 205.59 kHz. To ensure correct operation of the AD7713, the
value of the code loaded to these bits must be within this range. Failure to do this will result in unspecified operation of the device.
Changing the filter notch frequency, as well as the selected gain, impacts resolution. Tables I and II and Figure 2 show the effect of
the filter notch frequency and gain on the effective resolution of the AD7713. The output data rate (or effective conversion time) for
the device is equal to the frequency selected for the first notch of the filter. For example, if the first notch of the filter is selected at
10 Hz, then a new word is available at a 10 Hz rate or every 100 ms. If the first notch is at 200 Hz, a new word is available every 5 ms.
The settling time of the filter to a full-scale step input change is worst case 4
×
1/(output data rate). This settling time is to 100% of
the final value. For example, with the first filter notch at 100 Hz, the settling time of the filter to a full-scale step input change is
400 ms max. If the first notch is at 200 Hz, the settling time of the filter to a full-scale input step is 20 ms max. This settling time
can be reduced to 3
×
l/(output data rate) by synchronizing the step input change to a reset of the digital filter. In other words, if the
step input takes place with
SYNC
low, the settling time will be 3
×
l/(output data rate). If a change of channels takes place, the set-
tling time is 3
×
l/(output data rate) regardless of the
SYNC
input.
The –3 dB frequency is determined by the programmed first notch frequency according to the relationship: filter –3 dB frequency
= 0.262
×
first notch frequency.
