REV. 0
Information furnished by Analog Devices is believed to be accurate and
reliable. However, no responsibility is assumed by Analog Devices for its
use, nor for any infringements of patents or other rights of third parties that
may result from its use. No license is granted by implication or otherwise
under any patent or patent rights of Analog Devices.
a
AD8019
One Technology Way, P.O. Box 9106, Norwood, MA 02062-9106, U.S.A.
Tel: 781/329-4700
Fax: 781/326-8703
www.analog.com
Analog Devices, Inc., 2001
DSL Line Driver
with Power-Down
PIN CONFIGURATIONS
8
7
6
5
1
2
3
4
AD8019AR
–IN1
+IN1
–V
S
OUT1
OUT2
–IN2
+V
S
+IN2
14
13
12
11
10
9
8
1
2
3
4
5
6
7
AD8019ARU
NC = NO CONNECT
DGND
NC
PWDN
NC
NC
+V
S
NC
OUT1
–IN1
+IN1
–V
S
OUT2
–IN2
+IN2
FEATURES
Low Distortion, High Output Current Amplifiers
Operate from 12 V to 12 V Power Supplies,
Ideal for High-Performance ADSL CPE, and xDSL
Modems
Low Power Operation
9 mA/Amp (Typ) Supply Current
Digital (1-Bit) Power-Down
Voltage Feedback Amplifiers
Low Distortion
Out-of-Band SFDR –80 dBc @ 100 kHz into 100
High Speed
175 MHz Bandwidth (–3 dB), G = +1
400 V/ s Slew Rate
High Dynamic Range
V
OUT
to within 1.2 V of Power Supply
Line
APPLICATIONS
ADSL, VDSL, HDSL, and Proprietary xDSL USB, PCI,
PCMCIA Modems, and Customer Premise Equipment
(CPE)
PRODUCT DESCRIPTION
The AD8019 is a low cost xDSL line driver optimized to drive a
minimum of 13 dBm into a 100
load while delivering outstand-
ing distortion performance. The AD8019 is designed on a 24 V
high-speed bipolar process enabling the use of
±
12 V power
supplies or 12 V only. When operating from a single 12 V sup-
ply the highly efficient amplifier architecture can typically deliver
170 mA output current into low impedance loads through a
1:2 turns ratio transformer. Hybrid designs using
±
12 V supplies
enable the use of a 1:1 turns ratio transformer, minimizing attenu-
ation of the receive signal. The AD8019 typically draws 9 mA/
amplifier quiescent current. A 1-bit digital power down feature
reduces the quiescent current to approximately 1.6 mA/amplifier.
Figure 1 shows typical Out of Band SFDR performance under
ADSL CPE (upstream) conditions. SFDR is measured while
driving a 13 dBm ADSL DMT signal into a 100
line with
50
back termination.
The AD8019 comes in thermally enhanced 8-lead SOIC and
14-lead TSSOP packages. The 8-lead SOIC is pin-compatible
with the AD8017 12 V line driver.
FREQUENCY
–
kHz
132.5
1
137.5
142.5
–
80dBc
Figure 1. Out-of-Band SFDR; V
S
=
±
12 V; 13 dBm Output
Power into 200
, Upstream
8-Lead SOIC
(R-8)
14-Lead TSSOP
(RU-14)
