AD8055/AD8056
–10–
REV. 0
Power Dissipation Limits
With a 10 V supply (total V
CC
– V
EE
), the quiescent power dissi-
pation of the AD8055 in the SOT-23-5 package is 65 mW,
while the quiescent power dissipation of the AD8056 in the
microSOIC is 120 mW. This translates into a 15.6
°
C rise above
the ambient for the SOT-23-5 package and a 24
°
C rise for the
microSOIC package.
The power dissipated under heavy load conditions is approxi-
mately equal to the supply voltage minus the output voltage,
times the load current, plus the quiescent power computed above.
This total power dissipation is then multiplied by the thermal
resistance of the package to find the temperature rise, above
ambient, of the part. The junction temperature should be kept
below 150
°
C.
The AD8055 in the SOT-23-5 package can dissipate 270mW
while the AD8056 in the microSOIC package can dissipate
325 mW (at 85
°
C ambient) without exceeding the maximum
die temperature. In the case of the AD8056, this is greater than
1.5 V rms into 50
, enough to accommodate a 4 V p-p sinewave
signal on both outputs simultaneously. But since each output of
the AD8055 or AD8056 is capable of supplying as much as
110 mA into a short circuit, a continuous short circuit condition
will exceed the maximum safe junction temperature.
Resistor Selection
The following table is provided as a guide to resistor selection
for maintaining gain flatness vs. frequency for various values of
gain.
–3 dB
Bandwidth
(MHz)
Gain
R
F
(
V
)
R
I
(
V
)
+1
+2
+5
+10
0
402
1K
909
—
402
249
100
300
160
45
20
Driving Capacitive Loads
When driving a capacitive load, most op amps will exhibit peak-
ing in the frequency response just before the frequency rolls off.
Figure 36 shows the responses for an AD8056 running at a gain
of +2, with a 100
load that is shunted by various values of
capacitance. It can be seen that under these conditions, the part
is still stable with capacitive loads of up to 30 pF.
FREQUENCY – MHz
5
4
–5
0.3
500
1
10
100
1
–2
–3
–4
3
2
–1
0
N
C
L
= 30pF
C
L
= 20pF
C
L
= 10pF
C
L
= 0pF
402
C
L
100
402
50
V
IN
= 0dBm
Figure 36. Capacitive Load Drive
In general, to minimize peaking or to ensure the stability for
larger values of capacitive loads, a small series resistor, R
S,
can
be added between the op amp output and the capacitor, C
L
. For
the setup depicted in Figure 37, the relationship between R
S
and
C
L
was empirically derived and is shown in Figure 38. R
S
was
chosen to produce less than 1 dB of peaking in the frequency
response. Note also that after a sharp rise R
S
quickly settles to
about 25
.
V
IN
= 0dBm
50
AD8055
V
OUT
+5V
–5V
402
402
6
7
2
3
4
C
L
0.1μF
10μF
0.1μF
10μF
R
S
FET PROBE
Figure 37. Setup for R
S
vs. C
L
C
L
= pF
R
S
0
270
10
20
30
40
50
60
40
0
35
20
15
10
5
30
25
Figure 38. R
S
vs. C
L
