| 型號： | AD8123ACPZ-RL |
| 廠商： | ANALOG DEVICES INC |
| 元件分類： | 通用總線功能 |
| 英文描述： | Triple Differential Receiver with Adjustable Line Equalization |
| 中文描述： | LINE RECEIVER, QCC40 |
| 封裝： | 6 X 6MM, ROHS COMPLIANT, MO-220VJJD-2, LFCSP-40 |
| 文件頁數： | 16/16頁 |
| 文件大?。?/td> | 618K |
| 代理商： | AD8123ACPZ-RL |
AD8123
OUTLINE DIMENSIONS
Rev. 0 | Page 16 of 16
COMPLIANT TO JEDEC STANDARDS MO-220-VJJD-2
0
1
40
10
11
29
28
20
19
4.45
4.30 SQ
4.15
TOP
VIEW
6.00
BSC SQ
5.75
BCS SQ
COPLANARITY
0.08
4.50
REF
0.50
0.40
0.30
0.50
BSC
PIN 1
INDICATOR
0.60 MAX
0.60 MAX
0.25 MIN
EXPOSED
PAD
(BOT TOM VIEW)
INDICPIN 1
0.30
0.23
0.18
0.20 REF
12° MAX
0.80 MAX
0.65 TYP
1.00
0.85
0.80
0.05 MAX
0.02 NOM
SEATING
PLANE
Figure 34. 40-Lead Lead Frame Chip Scale Package [LFCSP_VQ]
6 mm × 6 mm, Very Thin Quad
(CP-40-4)
Dimensions shown in millimeters
ORDERING GUIDE
Model
AD8123ACPZ-R2
1
AD8123ACPZ-R7
1
AD8123ACPZ-RL
1
1
Z = RoHS Compliant Part.
Temperature Range
40°C to +85°C
40°C to +85°C
40°C to +85°C
Package Description
40-Lead LFCSP_VQ
40-Lead LFCSP_VQ
40-Lead LFCSP_VQ
Package Option
CP-40-4
CP-40-4
CP-40-4
2007 Analog Devices, Inc. All rights reserved. Trademarks and
registered trademarks are the property of their respective owners.
D06814-0-8/07(0)
