REV. B
AD8309
–3–
ABSOLUTE MAXIMUM RATINGS*
Supply Voltage V
S
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7.5 V
Input Level, Differential (re 50
) . . . . . . . . . . . . . . . +26 dBm
Input Level, Single-Ended (re 50
) . . . . . . . . . . . . . +20 dBm
Internal Power Dissipation . . . . . . . . . . . . . . . . . . . . .500 mW
θ
JA
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 150
°
C/W
θ
JC
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27.6
°
C/W
Maximum Junction Temperature . . . . . . . . . . . . . . . . +125
°
C
CAUTION
ESD (electrostatic discharge) sensitive device. Electrostatic charges as high as 4000 V readily
accumulate on the human body and test equipment and can discharge without detection.
Although the AD8309 features proprietary ESD protection circuitry, permanent damage may
occur on devices subjected to high energy electrostatic discharges. Therefore, proper ESD
precautions are recommended to avoid performance degradation or loss of functionality.
WARNING!
ESD SENSITIVE DEVICE
PIN CONFIGURATION
TOP VIEW
(Not to Scale)
16
15
14
13
12
11
10
9
1
2
3
4
5
6
7
8
COM2
VLOG
AD8309
VPS1
PADL
INHI
INLO
PADL
COM1
ENBL
VPS2
PADL
LMHI
LMLO
PADL
FLTR
LMDR
PIN FUNCTION DESCRIPTIONS
Pin
Name
Function
1
2
COM2
VPS1
Special Common Pin for RSSI Output.
Supply Pin for First Five Amplifier Stages
and the Main Biasing System.
Four Tie-Downs to the Paddle on Which
the IC Is Mounted; Grounded.
Signal Input, HI or Plus Polarity.
Signal Input, LO or Minus Polarity.
Main Common Connection.
Chip Enable; Active When HI.
LMDR Limiter Drive Programming Pin.
FLTR
RSSI Bandwidth-Reduction Pin.
LMLO
Limiter Output, LO or Minus Polarity.
LMHI
Limiter Output, HI or Plus Polarity.
VPS2
Supply Pin for Sixth Gain Stage, Limiter
and RSSI Output Stage Load Current.
VLOG
Logarithmic (RSSI) Output.
3, 6, 11, 14 PADL
4
5
7
8
9
10
12
13
15
INHI
INLO
COM1
ENBL
16
ORDERING GUIDE
Temperature
Range
–40
°
C to +85
°
C 16-Lead TSSOP
–40
°
C to +85
°
C 13" Tape and Reel RU-16
Package
Description
Package
Option
Model
AD8309ARU
AD8309ARU-REEL
AD8309ARU-REEL7 –40
°
C to +85
°
C 7" Tape and Reel
AD8309-EVAL
RU-16
RU-16
Evaluation Board
Operating Temperature Range . . . . . . . . . . . .–40
°
C to +85
°
C
Storage Temperature Range . . . . . . . . . . . . .–65
°
C to +150
°
C
Lead Temperature Range (Soldering 60 sec) . . . . . . . . +300
°
C
*Stresses above those listed under Absolute Maximum Ratings may cause perma-
nent damage to the device. This is a stress rating only; functional operation of the
device at these or any other conditions above those indicated in the operational
section of this specification is not implied. Exposure to absolute maximum rating
conditions for extended periods may effect device reliability.
