REV. 0
–4–
ADP3166
ABSOLUTE MAXIMUM RATINGS
*
VCC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . –0.3 V to +15 V
FBRTN . . . . . . . . . . . . . . . . . . . . . . . . . . . . .–0.3 V to +0.3 V
VID0 to VID4, EN, DELAY, ILIMIT, CSCOMP, RT, COMP,
CROWBAR, PWM1 to PWM4 . . . . . . . . .–0.3 V to +5.5 V
SW1 to SW4 . . . . . . . . . . . . . . . . . . . . . . . . . . .–5 V to +25 V
All Other Inputs and Outputs . . . . . . .–0.3 V to VCC + 0.3 V
Operating Ambient Temperature Range . . . . . . . 0
°
C to 85
°
C
Operating Junction Temperature . . . . . . . . . . . . . . . . . . 125
°
C
Storage Temperature Range . . . . . . . . . . . . –65
°
C to +150
°
C
JA
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 100
°
C/W
0
0.5
1.0
MASTER CLOCK FREQUENCY – MHz
1.5
2.0
2.5
3.0
3.5
4.0
5.3
5.2
5.1
5.0
4.9
4.8
4.7
4.6
S
T
= 25 C
4-PHASE OPERATION
TPC 1. Supply Current vs. Master Clock Frequency
ORDERING GUIDE
Temperature
Range
0
°
C to 85
°
C
0
°
C to 85
°
C
Package
Options
Quantity
per Reel
Model
ADP3166JRU-REEL7
ADP3166JRU-REEL
RU-28 (TSSOP-28)
RU-28 (TSSOP-28)
1000
2500
Lead Temperature (Soldering, 10 sec) . . . . . . . . . . . . . 300
°
C
Vapor Phase (60 sec) . . . . . . . . . . . . . . . . . . . . . . . . . . . 215
°
C
Infrared (15 sec) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 220
°
C
*
Stresses above those listed under Absolute Maximum Ratings may cause perma-
nent damage to the device. This is a stress rating only. Functional operation of the
device at these or any other conditions above those listed in the operational
sections of this specification is not implied. Exposure to absolute maximum rating
conditions for extended periods may affect device reliability. Absolute maximum
ratings apply individually only, not in combination. Unless otherwise specified, all
other voltages are referenced to GND.
4
3
2
1
0
M
RT VALUE – k
0
50
100
150
200
250
300
TPC 2. Master Clock Frequency vs. R
T
CAUTION
ESD (electrostatic discharge) sensitive device. Electrostatic charges as high as 4000 V readily
accumulate on the human body and test equipment and can discharge without detection. Although the
ADP3166 features proprietary ESD protection circuitry, permanent damage may occur on devices
subjected to high energy electrostatic discharges. Therefore, proper ESD precautions are recommended
to avoid performance degradation or loss of functionality.
