Rev. B
|
Page 2 of 48
|
August 2005
ADSP-21262
ADDITIONAL KEY FEATURES
2M bit on-chip dual-ported SRAM (1M bit block 0, 1M bit
block 1) for simultaneous access by core processor and
DMA
4M bit on-chip dual-ported mask-programmable ROM
(2M bit in block 0 and 2M bit in block 1)
Dual data address generators (DAGs) with modulo and bit-
reverse addressing
Zero-overhead looping with single-cycle loop setup,
providing efficient program sequencing
Single-instruction multiple-data (SIMD) architecture
provides:
Two computational processing elements
Concurrent execution—each processing element executes
the same instruction, but operates on different data
Parallelism in buses and computational units allows single
cycle executions (with or without SIMD) of a multiply
operation; an ALU operation; a dual memory read or
write; and an instruction fetch
Accelerated FFT butterfly computation through a multiply
with add and subtract instruction
DMA controller supports:
22 zero-overhead DMA channels for transfers between the
ADSP-21262 internal memory and serial ports (12), the
input data port (IDP) (eight), the SPI-compatible port
(one), and the parallel port (one)
32-bit background DMA transfers at core clock speed, in
parallel with full-speed processor execution
JTAG background telemetry for enhanced emulation
features
IEEE 1149.1 JTAG standard test access port and on-chip
emulation
Dual voltage: 3.3 V I/O, 1.2 V core
Available in 136-ball BGA and 144-lead LQFP packages
Also available in lead-free packages
Digital applications interface includes six serial ports, two
precision clock generators, an input data port, three pro-
grammable timers, and a signal routing unit
Asynchronous parallel/external port provides:
Access to asynchronous external memory
16 multiplexed address/data lines that can support 24-bit
address external address range with 8-bit data or 16-bit
address external address range with 16-bit data
66M byte/sec transfer rate for 200 MHz core rate
50M byte/sec transfer rate for 150 MHz core rate
256 word page boundaries
External memory access in a dedicated DMA channel
8-bit to 32-bit and 16-bit to 32-bit word packing options
Programmable wait state options: 2 to 31 CCLK
Serial ports provide:
Six dual data line serial ports that operate at up to
50M bit/sec for a 200 MHz core and up to 37.5M bit/sec
for a 150 MHz core on each data line—each has a clock,
frame sync, and two data lines that can be configured as
either a receiver or transmitter pair
Left-justified sample-pair and I
2
S support, programmable
direction for up to 24 simultaneous receive or transmit
channels using two I
2
S-compatible stereo devices per
serial port
TDM support for telecommunications interfaces including
128 TDM channel support for newer telephony inter-
faces such as H.100/H.110
Up to 12 TDM stream support, each with 128 channels
per frame
Companding selection on a per channel basis in TDM mode
Input data port provides an additional input path to the
SHARC core configurable as either eight channels of I
2
S or
serial data or as seven channels plus a single 20-bit wide
synchronous parallel data acquisition port
Supports receive audio channel data in I
2
S, left-justified
sample pair, or right-justified mode
Signal routing unit (SRU) provides configurable and flexible
connections between all DAI components, six serial ports,
two precision clock generators, three timers, an input data
port/parallel data acquisition port, 10 interrupts, six flag
inputs, six flag outputs, and 20 SRU I/O pins (DAI_Px)
Serial peripheral interface (SPI)
Master or slave serial boot through SPI
Full-duplex operation
Master-slave mode multimaster support
Open drain outputs
Programmable baud rates, clock polarities, and phases
3 Muxed Flag/IRQ lines
1 Muxed Flag/Timer expired line
ROM-based security features:
JTAG access to memory permitted with a 64-bit key
Protected memory regions that can be assigned to limit
access under program control to sensitive code
PLL has a wide variety of software and hardware multi-
plier/divider ratios
