Advanced Power
P-CHANNEL ENHANCEMENT MODE
Electronics Corp.
POWER MOSFET
▼ Lower On-resistance
BVDSS
-30V
▼ Simple Drive Requirement
RDS(ON)
9mΩ
▼ Fast Switching Characteristic
ID
-75A
Description
Absolute Maximum Ratings
Symbol
Units
VDS
V
VGS
V
ID@TC=25℃
A
ID@TC=100℃
A
IDM
A
PD@TC=25℃
W
W/℃
TSTG
℃
TJ
℃
Symbol
Value
Units
Rthj-c
Maximum Thermal Resistance, Junction-case
1.4
℃
/W
Rthj-a
62.5
℃
/W
Rthj-a
Maximum Thermal Resistance, Junction-ambient
110
℃
/W
Data and specifications subject to change without notice
200812304
RoHS-compliat Product
1
+25
-75
0.71
Maximum Thermal Resistance, Junction-ambient (PCB mount)
4
AP6679GH/J
Rating
-30
Continuous Drain Current, VGS @ 10V
-50
Pulsed Drain Current
1
-300
Parameter
Drain-Source Voltage
Gate-Source Voltage
Continuous Drain Current, VGS @ 10V
3
89
-55 to 150
Linear Derating Factor
-55 to 150
Thermal Data
Parameter
Total Power Dissipation
Operating Junction Temperature Range
Storage Temperature Range
G
D
S
G
D S
TO-252(H)
G
D
S
TO-251(J)
The TO-252 package is widely preferred for commercial-industrial
surface mount applications and suited for low voltage applications
such as DC/DC converters. The through-hole version (AP6679GJ) is
available for low-profile applications.
