5-76
ATF-36077 Electrical Specifications,
TC = 25°C, ZO = 50 , Vds = 1.5 V, Ids = 10 mA, (unless otherwise noted).
Symbol
Parameters and Test Conditions
Units
Min.
Typ.
Max.
NF
Noise Figure[1]
f = 12.0 GHz
dB
0.5
0.6
GA
Gain at NF[1]
f = 12.0 GHz
dB
11.0
12.0
gm
Transconductance
VDS = 1.5 V, VGS = 0 V
mS
50
55
Idss
Saturated Drain Current
VDS = 1.5 V, VGS = 0 V
mA
15
25
45
Vp10%
Pinch-off Voltage
VDS = 1.5 V, IDS = 10% of Idss
V
-1.0
-0.35
-0.15
Note:
1. Measured in a fixed tuned environment with
Γ source = 0.54 at 156°; Γ load = 0.48 at 167°.
Thermal Resistance[2,3]:
θ
ch-c = 60°C/W
Notes:
1. Operation of this device above any one
of these parameters may cause
permanent damage.
2. Measured at Pdiss = 15 mW and
Tch = 100°C.
3. Derate at 16.7 mW/
°C for T
C > 139°C.
ATF-36077 Absolute Maximum Ratings
Absolute
Symbol
Parameter
Units
Maximum[1]
VDS
Drain – Source Voltage
V
+3
VGS
Gate – Source Voltage
V
-3
VGD
Gate-Drain Voltage
V
-3.5
ID
Drain Current
mA
Idss
PT
Total Power Dissipation[3]
mW
180
Pin max
RF Input Power
dBm
+10
Tch
Channel Temperature
°C
150
TSTG
Storage Temperature
°C
-65 to 150
ATF-36077 Characterization Information,
TC = 25°C, ZO = 50 , Vds = 1.5 V, Ids = 10 mA, (unless otherwise noted).
Symbol
Parameters and Test Conditions
Units
Typ.
NF
Noise Figure (Tuned Circuit)
f = 4 GHz
dB
0.3[2]
f = 12 GHz
dB
0.5
GA
Gain at Noise Figure (Tuned Circuit)
f = 4 GHz
dB
17
f = 12 GHz
dB
12
S12 off
Reverse Isolation
f = 12 GHz, VDS = 1.5 V, VGS = -2 V
dB
14
P1dB
Output Power at 1 dB Gain Compression
f = 4 GHz
dBm
5
f = 12 GHz
dBm
5
VGS 10 mA
Gate to Source Voltage for IDS = 10 mA
VDS = 1.5 V
V
-0.2
Note:
2. See noise parameter table.
