- 您現在的位置：買賣IC網 > PDF目錄376671 > DF2S12FS (Toshiba Corporation) Zener Diode; Application: General; Pd (mW): 200; Vz (V): 8.85 to 9.23; Condition Iz at Vz (mA): 5; C (pF) max: -; Condition VR at C (V):   ESD (kV) min: -; Package: MPAK PDF資料下載
參數資料
| 型號： | DF2S12FS |
| 廠商： | Toshiba Corporation |
| 英文描述： | Zener Diode; Application: General; Pd (mW): 200; Vz (V): 8.85 to 9.23; Condition Iz at Vz (mA): 5; C (pF) max: -; Condition VR at C (V):   ESD (kV) min: -; Package: MPAK |
| 中文描述： | 產品使用，但對靜電放電（ESD）保護。 |
| 文件頁數： | 2/3頁 |
| 文件大?。?/td> | 164K |
| 代理商： | DF2S12FS |
DF2S12FS
2007-11-01
2
Guaranteed Level of ESD Immunity
Test Condition
ESD Immunity Level
IEC61000-4-2
(Contact discharge)
±
30 kV
Criterion: No damage to device elements
Marking
Equivalent Circuit
(Top View)
8
ZENER VOLTAGE VZ(V)
Z
REVERSE VOLTAGE VR(V)
T
