Jul. 2004
PRELIMINARY
Some parametric limits are subject to change.
Conditions
Applied for all condition angles
f = 60Hz, sinewave
θ
= 180
°
, T
f
=70
°
C
One half cycle at 60Hz, T
j
=150
°
C start
(Recommended value 47kN)
Typical value 1450g
7850
5000
70
2.0
×
10
7
–40 ~ 150
–40 ~ 150
39 ~ 55
—
MITSUBISHI RECTIFIER DIODE
FD5000AV-100DA
HIGH-POWER, GENERAL USE
PRESS PACK TYPE
FD5000AV-100DA
OUTLINE DRAWING
Dimensions in mm
APPLICATION
High-power inverters
Fly-hweel diode for GCT Thyristor
Power supplies as high frequency rectifiers
V
RRM
I
F(AV)
Repetitive peak reverse voltage
................... 5000V
Average forward current..................... 5000A
RMS forward current
Average forward current
Surge forward current
Current-squared, time integration
Operation junction temperature
Storage temperature
Mounting force required
Weight
A
A
kA
A
2
s
°
C
°
C
kN
g
I
F(RMS)
I
F(AV)
I
FSM
I
2
t
T
j
T
stg
—
—
Unit
Symbol
V
RRM
V
RSM
V
R(DC)
Repetitive peak reverse voltage
Non-repetitive peak reverse voltage
DC reverse voltage
Parameter
V
V
V
Symbol
Parameter
Unit
Ratings
MAXIMUM RATINGS
5000
5000
2000
Voltage class
—
—
—
Conditions
Forward voltage
Repetitive peak reverse current
Thermal resistance
V
FM
I
RRM
R
th(j-f)
V
mA
K/W
Symbol
Parameter
Test conditions
Limits
Typ.
—
—
—
Min.
—
—
—
Max.
1.6
200
0.0071
Unit
ELECTRICAL CHARACTERISTICS
I
FM
= 7000A, T
j
= 150
°
C
V
RM
= 5000V, T
j
= 150
°
C
Junction to Fin
φ
3.5
±
0.2
2.2
±
0.2DEPTH
φ
3.5
±
0.2
2.2
±
0.2DEPTH
6.35
×
10.8
φ
85
±
0.2
φ
85
±
0.2
φ
120MAX
12
±
2
1
±
2
±
TYPE NAME
0
0
