March 1998
FDN358P
P-Channel Logic Level Enhancement Mode Field Effect Transistor
General Description Features
Absolute Maximum Ratings
T
A
= 25
o
C unless other wise noted
Symbol
Parameter
FDN358P
Units
V
DSS
Drain-Source Voltage
-30
V
V
GSS
Gate-Source Voltage
±20
V
I
D
Drain/Output Current - Continuous
-1.5
A
- Pulsed
-5
P
D
Maximum Power Dissipation
(Note 1a)
0.5
W
(Note 1b)
0.46
T
J
,T
STG
Operating and Storage Temperature Range
-55 to 150
°C
THERMAL CHARACTERISTICS
R
θ
JA
R
θ
JC
Thermal Resistance, Junction-to-Ambient
(Note 1a)
250
°C/W
Thermal Resistance, Junction-to-Case
(Note 1)
75
°C/W
FDN358P Rev.D
-1.5 A, -30 V, R
DS(ON)
= 0.125
@ V
GS
= -10 V
R
DS(ON)
= 0.20
@ V
GS
= - 4.5 V.
High power version of industry SOT-23 package: identical
pin out to SOT-23; 30% higher power handling capability.
High density cell design for extremely low R
DS(ON)
.
Exceptional on-resistance and maximum DC current
capability.
SuperSOT
TM
-3 P-Channel logic level enhancement mode
power field effect transistors are produced using Fairchild's
proprietary, high cell density, DMOS technology. This very
high density process is especially tailored to minimize
on-state resistance. These devices are particularly suited for
low voltage applications in notebook computers, portable
phones, PCMCIA cards, and other battery powered circuits
where fast switching, and low in-line power loss are needed
in a very small outline surface mount package.
G
D
S
SuperSOT -3
358
SuperSOT
TM
-8
SOIC-16
SO-8
SOT-223
SuperSOT
TM
-3
SuperSOT
TM
-6
D
S
G
1998 Fairchild Semiconductor Corporation
