- 您現在的位置：買賣IC網 > PDF目錄375801 > FJP3307D (FAIRCHILD SEMICONDUCTOR CORP) High Voltage Fast Switching NPN Power Transistor PDF資料下載
參數資料
| 型號： | FJP3307D |
| 廠商： | FAIRCHILD SEMICONDUCTOR CORP |
| 元件分類： | 功率晶體管 |
| 英文描述： | High Voltage Fast Switching NPN Power Transistor |
| 中文描述： | 8 A, 400 V, NPN, Si, POWER TRANSISTOR, TO-220AB |
| 封裝： | LEAD FREE, TO-220, 3 PIN |
| 文件頁數： | 6/6頁 |
| 文件大小： | 155K |
| 代理商： | FJP3307D |
